B-48 C60 Breaker Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
8DC8 ...Repeated for Digital Element 45
8DDE ...Repeated for Digital Element 46
8DF4 ...Repeated for Digital Element 47
8E0A ...Repeated for Digital Element 48
Trip Bus (Read/Write Setting) (6 modules)
8ED0 Trip Bus 1 Function 0 to 1 --- 1 F102 0 (Disabled)
8ED1 Trip Bus 1 Block 0 to 4294967295 --- 1 F300 0
8ED3 Trip Bus 1 Pickup Delay 0 to 600 s 0.01 F001 0
8ED4 Trip Bus 1 Reset Delay 0 to 600 s 0.01 F001 0
8ED5 Trip Bus 1 Input (16 items) 0 to 4294967295 --- 1 F300 0
8EF5 Trip Bus 1 Latching 0 to 1 --- 1 F102 0 (Disabled)
8EF6 Trip Bus 1 Reset 0 to 4294967295 --- 1 F300 0
8EF8 Trip Bus 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
8EF9 Trip Bus 1 Events 0 to 1 --- 1 F102 0 (Disabled)
8EFA Reserved (8 items) 0 to 1 --- 1 F001 0
8F02 ...Repeated for Trip Bus 2
8F34 ...Repeated for Trip Bus 3
8F66 ...Repeated for Trip Bus 4
8F98 ...Repeated for Trip Bus 5
8FCA ...Repeated for Trip Bus 6
FlexElement (Read/Write Setting) (8 modules)
9000 FlexElement 1 Function 0 to 1 --- 1 F102 0 (Disabled)
9001 FlexElement 1 Name --- --- --- F206 “FxE 1”
9004 FlexElement 1 InputP 0 to 65535 --- 1 F600 0
9005 FlexElement 1 InputM 0 to 65535 --- 1 F600 0
9006 FlexElement 1 Compare 0 to 1 --- 1 F516 0 (LEVEL)
9007 FlexElement 1 Input 0 to 1 --- 1 F515 0 (SIGNED)
9008 FlexElement 1 Direction 0 to 1 --- 1 F517 0 (OVER)
9009 FlexElement 1 Hysteresis 0.1 to 50 % 0.1 F001 30
900A FlexElement 1 Pickup -90 to 90 pu 0.001 F004 1000
900C FlexElement 1 DeltaT Units 0 to 2 --- 1 F518 0 (Milliseconds)
900D FlexElement 1 DeltaT 20 to 86400 --- 1 F003 20
900F FlexElement 1 Pickup Delay 0 to 65.535 s 0.001 F001 0
9010 FlexElement 1 Reset Delay 0 to 65.535 s 0.001 F001 0
9011 FlexElement 1 Block 0 to 4294967295 --- 1 F300 0
9013 FlexElement 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
9014 FlexElement 1 Events 0 to 1 --- 1 F102 0 (Disabled)
9015 ...Repeated for FlexElement 2
902A ...Repeated for FlexElement 3
903F ...Repeated for FlexElement 4
9054 ...Repeated for FlexElement 5
9069 ...Repeated for FlexElement 6
907E ...Repeated for FlexElement 7
9093 ...Repeated for FlexElement 8
Fault Report Settings (Read/Write Setting)
9200 Fault Report 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
9201 Fault Report 1 Trigger 0 to 4294967295 --- 1 F300 0
9203 Fault Report 1 Z1 Magnitude 0.01 to 250 ohms 0.01 F001 300
9204 Fault Report 1 Z1 Angle 25 to 90 degrees 1 F001 75
9205 Fault Report 1 Z0 Magnitude 0.01 to 650 ohms 0.01 F001 900
9206 Fault Report 1 Z0 Angle 25 to 90 degrees 1 F001 75
9207 Fault Report 1 Line Length Units 0 to 1 --- 1 F147 0 (km)
9208 Fault Report 1 Line Length 0 to 2000 --- 0.1 F001 1000
9209 Fault Report 1 VT Substitution 0 to 2 --- 1 F270 0 (None)
Table B–10: MODBUS MEMORY MAP (Sheet 40 of 66)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
