GE Multilin C60 Breaker Protection System B-49
APPENDIX B B.4 MEMORY MAPPING
B
920A Fault Report 1 System Z0 Magnitude 0.01 to 650.00 ohms 0.01 F001 200
9208 Fault Report 1 System Z0 Angle 25 to 90 degrees 1 F001 75
920C Fault REM1-TAP Z1 Magnitude 0.01 to 250 ohms 0.01 F001 300
920D Fault REM1-TAP Z1 Angle 25 to 90 degrees 1 F001 75
920E Fault REM1-TAP Length 0 to 2000 --- 0.1 F001 1000
920F Fault REM2-TAP Z1 Magnitude 0.01 to 250 ohms 0.01 F001 300
9210 Fault REM2-TAP Z1 Angle 25 to 90 degrees 1 F001 75
9211 Fault REM2-TAP Length 0 to 2000 --- 0.1 F001 1000
DCmA Outputs (Read/Write Setting) (24 modules)
9360 DCmA Output 1 Source 0 to 65535 --- 1 F600 0
9361 DCmA Output 1 Range 0 to 2 --- 1 F522 0 (–1 to 1 mA)
9362 DCmA Output 1 Minimum –90 to 90 pu 0.001 F004 0
9364 DCmA Output 1 Maximum –90 to 90 pu 0.001 F004 1000
9366 ...Repeated for DCmA Output 2
936C ...Repeated for DCmA Output 3
9372 ...Repeated for DCmA Output 4
9378 ...Repeated for DCmA Output 5
937E ...Repeated for DCmA Output 6
9384 ...Repeated for DCmA Output 7
938A ...Repeated for DCmA Output 8
9390 ...Repeated for DCmA Output 9
9396 ...Repeated for DCmA Output 10
939C ...Repeated for DCmA Output 11
93A2 ...Repeated for DCmA Output 12
93A8 ...Repeated for DCmA Output 13
93AE ...Repeated for DCmA Output 14
93B4 ...Repeated for DCmA Output 15
93BA ...Repeated for DCmA Output 16
93C0 ...Repeated for DCmA Output 17
93C6 ...Repeated for DCmA Output 18
93CC ...Repeated for DCmA Output 19
93D2 ...Repeated for DCmA Output 20
93D8 ...Repeated for DCmA Output 21
93DE ...Repeated for DCmA Output 22
93E4 ...Repeated for DCmA Output 23
93EA ...Repeated for DCmA Output 24
Direct Input/Output Names (Read/Write Setting) (32 modules)
9400 Direct Input 1 Name 0 to 96 --- 1 F205 “Dir Ip 1”
9406 Direct Output 1 Name 1 to 96 --- 1 F205 “Dir Out 1”
940C ...Repeated for Direct Input/Output 2
9418 ...Repeated for Direct Input/Output 3
9424 ...Repeated for Direct Input/Output 4
9430 ...Repeated for Direct Input/Output 5
943C ...Repeated for Direct Input/Output 6
9448 ...Repeated for Direct Input/Output 7
9454 ...Repeated for Direct Input/Output 8
9460 ...Repeated for Direct Input/Output 9
946C ...Repeated for Direct Input/Output 10
9478 ...Repeated for Direct Input/Output 11
9484 ...Repeated for Direct Input/Output 12
9490 ...Repeated for Direct Input/Output 13
949C ...Repeated for Direct Input/Output 14
94A8 ...Repeated for Direct Input/Output 15
94B4 ...Repeated for Direct Input/Output 16
Table B–10: MODBUS MEMORY MAP (Sheet 41 of 66)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
