GE C60

GE Multilin C60 Breaker Protection System B-55
APPENDIX B B.4 MEMORY MAPPING
B
AFE9 ...Repeated for IEC 61850 GGIO4 Analog Input 32
IEC 61850 GOOSE/GSSE Configuration (Read/Write Setting)
B01C Default GOOSE/GSSE Update Time 1 to 60 s 1 F001 60
B01D IEC 61850 GSSE Function (GsEna) 0 to 1 --- 1 F102 1 (Enabled)
B01E IEC 61850 GSSE ID --- --- --- F209 “GSSEOut”
B03F IEC 61850 GOOSE Function (GoEna) 0 to 1 --- 1 F102 0 (Disabled)
B040 IEC 61850 GSSE Destination MAC Address --- --- --- F072 0
B043 IEC 61850 Standard GOOSE ID --- --- --- F209 “GOOSEOut”
B064 IEC 61850 Standard GOOSE Destination MAC Address --- --- --- F072 0
B067 IEC 61850 GOOSE VLAN Transmit Priority 0 to 7 --- 1 F001 4
B068 IEC 61850 GOOSE VLAN ID 0 to 4095 --- 1 F001 0
B069 IEC 61850 GOOSE ETYPE APPID 0 to 16383 --- 1 F001 0
B06A Reserved (2 items) 0 to 1 --- 1 F001 0
IEC 61850 Server Configuration (Read/Write Settings/Commands)
B06C TCP Port Number for the IEC 61850 / MMS Protocol 0 to 65535 --- 1 F001 102
B06D IEC 61850 Logical Device Name --- --- --- F213 “IEDName”
B07D IEC 61850 Logical Device Instance --- --- --- F213 “LDInst”
B08D IEC 61850 LPHD Location 0 to 65534 --- 1 F204 “Location”
B0B5 Include non-IEC 61850 Data 0 to 1 --- 1 F102 0 (Disabled)
B0B6 IEC 61850 Server Data Scanning Function 0 to 1 --- 1 F102 0 (Disabled)
B0B7 IEC 61850 LPHD Latitude -90 to 90 degrees 0.001 F004 0
B0B9 IEC 61850 LPHD DC PhyNam Longitude -180 to 180 degrees 0.001 F004 0
B9BB IEC 61850 LPHD DC PhyNam Altitude 0 to 10000 m 1 F003 0
B0BD Reserved (3 items) 0 to 1 --- 1 F001 0
IEC 61850 MMXU Deadbands (Read/Write Setting) (6 modules)
B0C0 IEC 61850 MMXU TotW Deadband 1 0.001 to 100 % 0.001 F003 10000
B0C2 IEC 61850 MMXU TotVAr Deadband 1 0.001 to 100 % 0.001 F003 10000
B0C4 IEC 61850 MMXU TotVA Deadband 1 0.001 to 100 % 0.001 F003 10000
B0C6 IEC 61850 MMXU TotPF Deadband 1 0.001 to 100 % 0.001 F003 10000
B0C8 IEC 61850 MMXU Hz Deadband 1 0.001 to 100 % 0.001 F003 10000
B0CA IEC 61850 MMXU PPV.phsAB Deadband 1 0.001 to 100 % 0.001 F003 10000
B0CC IEC 61850 MMXU PPV.phsBC Deadband 1 0.001 to 100 % 0.001 F003 10000
B0CE IEC 61850 MMXU PPV.phsCA Deadband 1 0.001 to 100 % 0.001 F003 10000
B0D0 IEC 61850 MMXU PhV.phsA Deadband 1 0.001 to 100 % 0.001 F003 10000
B0D2 IEC 61850 MMXU PhV.phsB Deadband 1 0.001 to 100 % 0.001 F003 10000
B0D4 IEC 61850 MMXU PhV.phsC Deadband 1 0.001 to 100 % 0.001 F003 10000
B0D6 IEC 61850 MMXU A.phsA Deadband 1 0.001 to 100 % 0.001 F003 10000
B0D8 IEC 61850 MMXU A.phsB Deadband 1 0.001 to 100 % 0.001 F003 10000
B0DA IEC 61850 MMXU A.phsC Deadband 1 0.001 to 100 % 0.001 F003 10000
B0DC IEC 61850 MMXU A.neut Deadband 1 0.001 to 100 % 0.001 F003 10000
B0DE IEC 61850 MMXU W.phsA Deadband 1 0.001 to 100 % 0.001 F003 10000
B0E0 IEC 61850 MMXU W.phsB Deadband 1 0.001 to 100 % 0.001 F003 10000
B0E2 IEC 61850 MMXU W.phsC Deadband 1 0.001 to 100 % 0.001 F003 10000
B0E4 IEC 61850 MMXU VAr.phsA Deadband 1 0.001 to 100 % 0.001 F003 10000
B0E6 IEC 61850 MMXU VAr.phsB Deadband 1 0.001 to 100 % 0.001 F003 10000
B0E8 IEC 61850 MMXU VAr.phsC Deadband 1 0.001 to 100 % 0.001 F003 10000
B0EA IEC 61850 MMXU VA.phsA Deadband 1 0.001 to 100 % 0.001 F003 10000
B0EC IEC 61850 MMXU VA.phsB Deadband 1 0.001 to 100 % 0.001 F003 10000
B0EE IEC 61850 MMXU VA.phsC Deadband 1 0.001 to 100 % 0.001 F003 10000
B0F0 IEC 61850 MMXU PF.phsA Deadband 1 0.001 to 100 % 0.001 F003 10000
B0F2 IEC 61850 MMXU PF.phsB Deadband 1 0.001 to 100 % 0.001 F003 10000
B0F4 IEC 61850 MMXU PF.phsC Deadband 1 0.001 to 100 % 0.001 F003 10000
B0F6 ...Repeated for Deadband 2
B12C ...Repeated for Deadband 3
Table B–10: MODBUS MEMORY MAP (Sheet 47 of 66)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
