GE C60

B-56 C60 Breaker Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
B162 ...Repeated for Deadband 4
B198 ...Repeated for Deadband 5
B1CE ...Repeated for Deadband 6
IEC 61850 Received Analogs (Read Only) (32 modules)
B210 IEC 61850 Received Analog 1 -1000000000000 to
1000000000000
--- 0.001 F060 0
B212 ...Repeated for Received Analog 2
B214 ...Repeated for Received Analog 3
B216 ...Repeated for Received Analog 4
B218 ...Repeated for Received Analog 5
B21A ...Repeated for Received Analog 6
B21C ...Repeated for Received Analog 7
B21E ...Repeated for Received Analog 8
B220 ...Repeated for Received Analog 9
B222 ...Repeated for Received Analog 10
B224 ...Repeated for Received Analog 11
B226 ...Repeated for Received Analog 12
B228 ...Repeated for Received Analog 13
B22A ...Repeated for Received Analog 14
B22C ...Repeated for Received Analog 15
B22E ...Repeated for Received Analog 16
B230 ...Repeated for Received Analog 17
B232 ...Repeated for Received Analog 18
B234 ...Repeated for Received Analog 19
B236 ...Repeated for Received Analog 20
B238 ...Repeated for Received Analog 21
B23A ...Repeated for Received Analog 22
B23C ...Repeated for Received Analog 23
B23E ...Repeated for Received Analog 24
B240 ...Repeated for Received Analog 25
B242 ...Repeated for Received Analog 26
B244 ...Repeated for Received Analog 27
B246 ...Repeated for Received Analog 28
B248 ...Repeated for Received Analog 29
B24A ...Repeated for Received Analog 30
B24C ...Repeated for Received Analog 31
B24E ...Repeated for Received Analog 32
IEC 61850 Configurable Report Settings (Read/Write Setting)
B290 IEC 61850 Configurable Reports Dataset Items (64 items) 0 to 848 --- 1 F615 0 (None)
IEC 61850 XSWI Configuration (Read/Write Setting) (24 modules)
B370 FlexLogic Operand for IEC 61850 XSWI.ST.Loc Status 0 to 4294967295 --- 1 F300 0
B373 ...Repeated for module number 2
B376 ...Repeated for module number 3
B379 ...Repeated for module number 4
B37C ...Repeated for module number 5
B37F ...Repeated for module number 6
B382 ...Repeated for module number 7
B385 ...Repeated for module number 8
B388 ...Repeated for module number 9
B38B ...Repeated for module number 10
B38E ...Repeated for module number 11
B391 ...Repeated for module number 12
B394 ...Repeated for module number 13
B397 ...Repeated for module number 14
Table B–10: MODBUS MEMORY MAP (Sheet 48 of 66)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
