GE Multilin C60 Breaker Protection System B-57
APPENDIX B B.4 MEMORY MAPPING
B
B39A ...Repeated for module number 15
B39D ...Repeated for module number 16
B3A0 ...Repeated for module number 17
B3A3 ...Repeated for module number 18
B3A6 ...Repeated for module number 19
B3A9 ...Repeated for module number 20
B3AC ...Repeated for module number 21
B3AF ...Repeated for module number 22
B3B2 ...Repeated for module number 23
B3B5 ...Repeated for module number 24
IEC 61850 XSWI Configuration (Read/Write Command) (24 modules)
B372 Command to Clear XSWI OpCnt (Operation Counter) 0 to 1 --- 1 F126 0 (No)
IEC 61850 GGIO1 Configuration Settings (Read/Write Setting)
B400 Number of Status Indications in GGIO1 8 to 128 --- 8 F001 8
B402 IEC 61850 GGIO1 Indication FlexLogic operands (128
items)
0 to 4294967295 --- 1 F300 0
IEC 61850 Configurable GOOSE Transmission (Read/Write Setting) (8 modules)
B5A0 IEC 61850 Configurable GOOSE Function (GoEna) 0 to 1 --- 1 F102 1 (Enabled)
B5A1 IEC 61850 Configurable GOOSE ID --- --- --- F209 “GOOSEOut_x_”
B5C2 Configurable GOOSE Destination MAC Address --- --- --- F072 0
B5C5 IEC 61850 Configurable GOOSE VLAN Transmit Priority 0 to 7 --- 1 F001 4
B5C6 IEC 61850 Configurable GOOSE VLAN ID 0 to 4095 --- 1 F001 0
B5C7 IEC 61850 Configurable GOOSE ETYPE APPID 0 to 16383 --- 1 F001 0
B5C8 IEC 61850 Configurable GOOSE ConfRev (Configuration
Revision)
1 to 4294967295 --- 1 F003 1
B5CA IEC 61850 Configurable GOOSE Retransmission Curve 0 to 3 --- 1 F611 3 (Relaxed)
B5CB Configurable GOOSE Dataset Items for Transmission
(64 items)
0 to 1008 --- 1 F616 0 (None)
B60B ...Repeated for module number 2
B676 ...Repeated for module number 3
B6E1 ...Repeated for module number 4
B74C ...Repeated for module number 5
B7B7 ...Repeated for module number 6
B822 ...Repeated for module number 7
B88D ...Repeated for module number 8
IEC 61850 Configurable GOOSE Reception (Read/Write Setting) (16 modules)
B900 Configurable GOOSE Dataset Items for Reception
(32 items)
0 to 197 --- 1 F233 0 (None)
B920 ...Repeated for module number 2
B940 ...Repeated for module number 3
B960 ...Repeated for module number 4
B980 ...Repeated for module number 5
B9A0 ...Repeated for module number 6
B9C0 ...Repeated for module number 7
B9E0 ...Repeated for module number 8
BA00 ...Repeated for module number 9
BA20 ...Repeated for module number 10
BA40 ...Repeated for module number 11
BA60 ...Repeated for module number 12
BA80 ...Repeated for module number 13
BAA0 ...Repeated for module number 14
BAC0 ...Repeated for module number 15
BAE0 ...Repeated for module number 16
Contact Inputs (Read/Write Setting) (96 modules)
BB00 Contact Input 1 Name --- --- --- F205 “Cont Ip 1“
Table B–10: MODBUS MEMORY MAP (Sheet 49 of 66)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
