GE C60 User Manual

GE Multilin C60 Breaker Protection System B-79
APPENDIX B B.4 MEMORY MAPPING
B
F126
ENUMERATION: NO/YES CHOICE
0 = No, 1 = Yes
F127
ENUMERATION: LATCHED OR SELF-RESETTING
0 = Latched, 1 = Self-Reset
F128
ENUMERATION: CONTACT INPUT THRESHOLD
0 = 17 V DC, 1 = 33 V DC, 2 = 84 V DC, 3 = 166 V DC
F129
ENUMERATION: FLEXLOGIC TIMER TYPE
0 = millisecond, 1 = second, 2 = minute
F131
ENUMERATION: FORCED CONTACT OUTPUT STATE
0 = Disabled, 1 = Energized, 2 = De-energized, 3 = Freeze
F132
ENUMERATION: DEMAND INTERVAL
0 = 5 min, 1 = 10 min, 2 = 15 min, 3 = 20 min, 4 = 30 min,
5 = 60 min
F133
ENUMERATION: PROGRAM STATE
0 = Not Programmed, 1 = Programmed
F134
ENUMERATION: PASS/FAIL
0 = Fail, 1 = OK, 2 = n/a
F137
ENUMERATION: USER-PROGRAMMABLE PUSHBUTTON
FUNCTION
0 = Disabled, 1 = Self-Reset, 2 = Latched
F139
ENUMERATION: DEMAND CALCULATIONS
0 = Thermal Exponential, 1 = Block Interval, 2 = Rolling Demand
F141
ENUMERATION: SELF TEST ERRORS
900 User-Programmable Pushbutton 1
901 User-Programmable Pushbutton 2
902 User-Programmable Pushbutton 3
903 User-Programmable Pushbutton 4
904 User-Programmable Pushbutton 5
905 User-Programmable Pushbutton 6
906 User-Programmable Pushbutton 7
907 User-Programmable Pushbutton 8
908 User-Programmable Pushbutton 9
909 User-Programmable Pushbutton 10
910 User-Programmable Pushbutton 11
911 User-Programmable Pushbutton 12
912 User-Programmable Pushbutton 13
913 User-Programmable Pushbutton 14
914 User-Programmable Pushbutton 15
915 User-Programmable Pushbutton 16
920 Disconnect switch 1
921 Disconnect switch 2
922 Disconnect switch 3
923 Disconnect switch 4
924 Disconnect switch 5
925 Disconnect switch 6
926 Disconnect switch 7
927 Disconnect switch 8
928 Disconnect switch 9
929 Disconnect switch 10
930 Disconnect switch 11
931 Disconnect switch 12
932 Disconnect switch 13
933 Disconnect switch 14
934 Disconnect switch 15
935 Disconnect switch 16
968 Breaker 1
969 Breaker 2
970 Breaker 3
971 Breaker 4
980 Breaker restrike 1
981 Breaker restrike 2
1012 Thermal overload protection 1
1013 Thermal overload protection 2
Bitmask Element
Bitmask Error
0 Any Self Tests
1 IRIG-B Failure
2 Port 1 Offline
3 Port 2 Offline
4 Port 3 Offline
5 Port 4 Offline
6 Port 5 Offline
7 Port 6 Offline
8 RRTD Communications Failure
9 Voltage Monitor
10 FlexLogic Error Token
