B.4 MEMORY MAPPING APPENDIX B
B
F143
UR_UINT32: 32 BIT ERROR CODE (F141 specifies bit number)
A bit value of 0 = no error, 1 = error
F144
ENUMERATION: FORCED CONTACT INPUT STATE
0 = Disabled, 1 = Open, 2 = Closed
F146
ENUMERATION: MISCELLANEOUS EVENT CAUSES
11 Equipment Mismatch
12 Process Bus Failure
13 Unit Not Programmed
14 System Exception
15 Latching Output Discrepancy
17 Maintenance Alert 01
18 SNTP Failure
19 Maintenance Alert
20 Maintenance Alert
21 Maintenance Alert
22 Temperature Monitor
23 Process Bus Trouble
24 Brick Trouble
25 Field RTD Trouble
26 Field TDR Trouble
27 Remote Device Offline
28 Direct Device Offline
29 Maintenance Alert
30 Any Minor Error
31 Any Major Error
33 Maintenance Alert
64 Maintenance Alert
65 IEC 61850 Data Set
66 Aggregator Error
67 Unit Not Calibrated
68 Settings Save Error
69 SRAM Data Error
70 Program Memory
71 Watchdog Error
72 Low On Memory
73 Prototype Firmware
74 Module Failure 01
75 Module Failure 02
76 Module Failure 03
77 Module Failure 04
78 Module Failure 05
79 Module Failure 06
80 Module Failure 07
81 Module Failure 08
82 Module Failure 09
83 Incompatible H/W
84 Module Failure 10
85 Module Failure 11
86 Module Failure 12
87 High ENET Traffic
89 Relay Restart
90 FGM Failure
91 FGM Failure
92 FGM Failure
93 FGM Failure
94 FGM Failure
95 FGM Error
96 Maintenance Alert
Bitmask Error
97 PHY Monitor
98 Storage Media Alarm
99 Wrong Transceiver
100 Power Supply Warning
Bitmask Definition
0 Events Cleared
1 Oscillography Triggered
2 Date/time Changed
3 Default Settings Loaded
4 Test Mode Forcing On
5 Test Mode Forcing Off
6 Power On
7 Power Off
8 Relay In Service
9 Relay Out Of Service
10 Watchdog Reset
11 Oscillography Clear
12 Reboot Command
13 Led Test Initiated
14 Flash Programming
15 Fault Report Trigger
16 User Programmable Fault Report Trigger
17 ---
18 Reload CT/VT module Settings
19 ---
20 Ethernet Port 1 Offline
21 Ethernet Port 2 Offline
22 Ethernet Port 3 Offline
23 Ethernet Port 4 Offline
24 Ethernet Port 5 Offline
25 Ethernet Port 6 Offline
26 Test Mode Isolated
27 Test Mode Forcible
28 Test Mode Disabled
29 Temperature Warning On
30 Temperature Warning Off
31 Unauthorized Access
32 System Integrity Recovery
33 System Integrity Recovery 06
Bitmask Error
