GE C60

GE Multilin C60 Breaker Protection System B-87
APPENDIX B B.4 MEMORY MAPPING
B
F238
ENUMERATION: REAL TIME CLOCK DAY (FOR EXAMPLE,
DAYLIGHT SAVINGS TIME)
F239
ENUMERATION: REAL TIME CLOCK DAYLIGHT SAVINGS
TIME START DAY INSTANCE
F243
ENUMERATION: FIELD UNIT TYPE
0 = CC-05, 1 = CV-05, 2 = CC-01, 3 = CV-01
F244
ENUMERATION: FIELD UNIT PROCESS CARD PORT
0 = H4a, 1 = H4b, 2 = H3a, 3 = H3b, 4 = H2a, 5 = H2b, 6 = H1a,
7 = H1b
F245
ENUMERATION: TEST MODE FUNCTION
F246
ENUMERATION: BRICK TRANSDUCER RANGE
F247
ENUMERATION: BRICK AC BANK ORIGIN
F248
ENUMERATION: BRICK AUX BANK ORIGIN
1 February
2March
3April
4May
5June
6July
7 August
8 September
9 October
10 November
11 December
Value Day
0 Sunday
1 Monday
2 Tuesday
3 Wednesday
4 Thursday
5 Friday
6 Saturday
Value Instance
0First
1 Second
2Third
3Fourth
4 Last
Value Instance
0Disabled
1 Isolated
2 Forcible
Value Month
Value Description
0 -5...5V
1 -1...1mA
20...1mA
30...-1mA
40...5mA
50...10mA
60...20mA
74...20mA
8 potentiometer
9 tap position
Value Description
0None
1U1/AC1..3
2U1/AC5..7
3U2/AC1..3
4U2/AC5..7
5U3/AC1..3
6U3/AC5..7
7U4/AC1..3
8U4/AC5..7
9U5/AC1..3
10 U5/AC5..7
11 U6/AC1..3
12 U6/AC5..7
13 U7/AC1..3
14 U7/AC5..7
15 U8/AC1..3
16 U8/AC5..7
Value Description
0None
1U1/AC4
2U1/AC8
3U2/AC4
4U2/AC8
5U3/AC4
6U3/AC8
7U4/AC4
8U4/AC8
9U5/AC4
10 U5/AC8
11 U6/AC4
