GE C60

B-88 C60 Breaker Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
F253
ENUMERATION: BRICK TRANSDUCER ORIGIN
F256
ENUMERATION: BRICK ORIGIN/DESTINATION
F259
ENUMERATION: BRICK RTD TYPE
0 = 100 Ohm Nickel, 1 = 120 Ohm Nickel, 2 = 100 Ohm Platinum
F260
ENUMERATION: DATA LOGGER MODE
0 = Continuous, 1 = Trigger
F261
ENUMERATION: BANK REDUNDANCY TYPE
0 = None, 1 = Dependability Biased, 2 = Security Biased
F262
ENUMERATION: BRICK STATUS
0 = Disabled, 1 = OK, 2 = Communications Trouble, 3 = Equip-
ment Mismatch, 4 = Brick Trouble
F270
ENUMERATION: FAULT REPORT VT SUBSTITUTION
F300
UR_UINT32: FLEXLOGIC BASE TYPE (15-bit type)
The FlexLogic BASE type is 14 bits and is combined with a 17-bit
descriptor and 1 bit for the protection element to form a 32-bit
value. The combined bits are of the form:
PTTTTTTTTTTTTTTDDDDDDDDDDDDDDDDD, where P bit if
set indicates that the FlexLogic type is associated with a protection
element state and D represents bits for the type in F124 format. If
P bit is not set, then the T represents bits for the type and D repre-
sents range.
The values in square brackets indicate the base type with P prefix
[PTTTTTTTTTTTTTT] and the values in round brackets indicate
the descriptor range. The left-most D bit indicates whether the type
is an ON or OFF type. There can be a total 65535 BASE type ele-
ments, 131071 protection element IDs, and 16383 element states.
There can be a total of 65535 descriptors of each type.
[0] Off (0) – This is boolean FALSE value
[1] On (1) – This is boolean TRUE value
[2] CONTACT INPUTS (1 to 96)
[3] CONTACT INPUTS OFF (1 to 96)
[4] VIRTUAL INPUTS (1 to 32)
[6] VIRTUAL OUTPUTS (1 to 64)
[8] CONTACT OUTPUTS
[10] CONTACT OUTPUTS VOLTAGE DETECTED (1 to 64)
[11] CONTACT OUTPUTS VOLTAGE OFF DETECTED (1 to 64)
[12] CONTACT OUTPUTS CURRENT DETECTED (1 to 64)
[13] CONTACT OUTPUTS CURRENT OFF DETECTED (1 to 64)
[14] REMOTE INPUTS (1 to 32)
[16] DIRECT INPUTS (1 to 96
[18] REMOTE OUTPUT DNA BIT PAIRS (1 to 32)
[20] REMOTE OUTPUT UserSt BIT PAIRS (1 to 32)
[22] REMOTE DEVICE ONLINE (1 to 16)
[24] MISCELLANEOUS EQUATION
[26] TELEPROTECTION INPUTS
[28] INSERT (via keypad only)
[30] DELETE (via keypad only)
[32] END
[34] NOT (1 INPUT)
[36] 2 INPUT XOR (0)
[38] LATCH SET/RESET (2 inputs)
[40] OR (2 to 16 inputs)
[42] AND (2 to 16 inputs)
[44] NOR (2 to 16 inputs)
[46] NAND (2 to 16 inputs)
[48] TIMER (1 to 32)
[50] ASSIGN VIRTUAL OUTPUT (1 to 64)
[52] ONE SHOT
[54] SELF-TEST ERROR (see F141 for range)
[56] PLATFORM DIRECT INPUT (1 to 96)
[58] PLATFORM DIRECT OUTPUT (1 to 96)
[60] PLATFORM DIRECT DEVICE (1 to 8)
[62] MISCELLANEOUS EVENTS (see F146 for range)
[64] PDC NETWORK CONTROL
12 U6/AC8
13 U7/AC5
14 U7/AC8
15 U8/AC5
16 U8/AC8
Value Description
0None
1 U1/DC1
2 U1/DC2
3 U1/DC3
4 U2/DC1
... ...
24 U8/DC3
Value Description
0None
1U1
2U2
3U3
4U4
5U5
6U6
7U7
8U8
Value Description
Value Description
0None
1I0
2V0
