GE C60

B-90 C60 Breaker Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
F530
ENUMERATION: FRONT PANEL INTERFACE KEYPRESS
F531
ENUMERATION: LANGUAGE
0 = English, 1 = French, 2 = Chinese, 3 = Russian, 4 = Turkish, 5 =
German
F542
ENUMERATION: PMU TRIGGERING MODE
0 = Automatic Overwrite, 1 = Protected
F543
ENUMERATION: PMU PHASORS
F544
ENUMERATION: PMU RECORDING/REPORTING RATE
F546
ENUMERATION: PMU REPORTING STYLE
0 = Polar, 1 = Rectangular
F547
ENUMERATION: PMU REPORTING FORMAT
0 = Integer, 1 = Floating
F548
ENUMERATION: PMU COM PROTOCOL
0 = NONE, 1 = 37.118, 2 = 61850-90-5
F549
ENUMERATION: PMU PERFORMANCE CLASS
0 = None, 1 = M-CLASS, 2 = P-CLASS
F563
ENUMERATION: DSCP TYPE
F600
UR_UINT16: FLEXANALOG PARAMETER
Corresponds to the Modbus address of the value used when this
parameter is selected. Only certain values can be used as FlexAn-
alogs (basically all metering quantities used in protection).
F601
ENUMERATION: COM2 PORT USAGE
F605
ENUMERATION: REMOTE DOUBLE-POINT STATUS INPUT
STATUS
Value Keypress Value Keypress Value Keypress
0 None 15 3 33 User PB 3
1 Menu 16 Enter 34 User PB 4
2 Message Up 17 Message
Down
35 User PB 5
37
~
18 0
~
36 User PB 6
4 8 19 Decimal 37 User PB 7
5 9 20 +/– 38 User PB 8
6 Help 21 Value Up 39 User PB 9
7 Message Left 22 Value Down 40 User PB 10
8 4 23 Reset 41 User PB 11
9 5 24 User 1 42 User PB 12
10 6 25User 2 44User 4
11 Escape 26 User 3 45 User 5
12 Message
Right
31 User PB 1 46 User 6
13 1 32 User PB 2 47 User 7
14 2
Value Phasor Value Phasor
0Off 8 Ig
1Va 9V1
2Vb 10V2
3Vc 11V0
4Vx 12I1
5Ia 13I2
6Ib 14I0
7Ic
Value Rate Value Rate
0 1/second 7 20second
1 2/second 8 25/second
2 4/second 9 30/second
3 5/second 10 50/second
4 10/second 11 60/second
5 12/second 12 100/second
6 15/second 13 120/second
Enumeration DSCP type
0None
1 Expedited Forwarding
Enumeration COM2 port usage
0 RS485
1RRTD
2 GPM-F
3 RRTD and GPM-F
Enumeration Remote DPS input status
0 Intermediate
1Off
2On
3Bad
Value Rate Value Rate
