GE C60

GE Multilin C60 Breaker Protection System B-91
APPENDIX B B.4 MEMORY MAPPING
B
F606
ENUMERATION: REMOTE DOUBLE-POINT STATUS INPUT
F610
ENUMERATION: SINGLE-POLE AUTORECLOSE INITIATION
MODE
F611
ENUMERATION: GOOSE RETRANSMISSION CURVE
F612
UR_UINT16: FLEXINTEGER PARAMETER
This 16-bit value corresponds to the Modbus address of the
selected FlexInteger parameter. Only certain values can be used
as FlexIntegers. There is no operation executed even though they
are called FlexIntegers.
F615
ENUMERATION: IEC 61850 REPORT DATASET ITEMS
Enumeration Remote double-point status input
0None
1 Remote input 1
2 Remote input 2
3 Remote input 3
↓↓
64 Remote input 64
Enumeration Initiation mode
0 Protection AND CB
1 Protection Only
Enumeration Configurable GOOSE retransmission scheme
0 Heartbeat
1 Aggressive
2Medium
3 Relaxed
Enumeration IEC 61850 report dataset items
0None
1 PDIF1.ST.Str.general
2 PDIF1.ST.Op.general
3 PDIF2.ST.Str.general
4 PDIF2.ST.Op.general
5 PDIF3.ST.Str.general
6 PDIF3.ST.Op.general
7 PDIF4.ST.Str.general
8 PDIF4.ST.Op.general
9 PDIS1.ST.Str.general
10 PDIS1.ST.Op.general
11 PDIS2.ST.Str.general
12 PDIS2.ST.Op.general
13 PDIS3.ST.Str.general
14 PDIS3.ST.Op.general
15 PDIS4.ST.Str.general
16 PDIS4.ST.Op.general
17 PDIS5.ST.Str.general
18 PDIS5.ST.Op.general
19 PDIS6.ST.Str.general
20 PDIS6.ST.Op.general
21 PDIS7.ST.Str.general
22 PDIS7.ST.Op.general
23 PDIS8.ST.Str.general
24 PDIS8.ST.Op.general
25 PDIS9.ST.Str.general
26 PDIS9.ST.Op.general
27 PDIS10.ST.Str.general
28 PDIS10.ST.Op.general
29 PIOC1.ST.Str.general
30 PIOC1.ST.Op.general
31 PIOC2.ST.Str.general
32 PIOC2.ST.Op.general
33 PIOC3.ST.Str.general
34 PIOC3.ST.Op.general
35 PIOC4.ST.Str.general
36 PIOC4.ST.Op.general
37 PIOC5.ST.Str.general
38 PIOC5.ST.Op.general
39 PIOC6.ST.Str.general
40 PIOC6.ST.Op.general
41 PIOC7.ST.Str.general
42 PIOC7.ST.Op.general
43 PIOC8.ST.Str.general
44 PIOC8.ST.Op.general
45 PIOC9.ST.Str.general
46 PIOC9.ST.Op.general
47 PIOC10.ST.Str.general
48 PIOC10.ST.Op.general
49 PIOC11.ST.Str.general
50 PIOC11.ST.Op.general
51 PIOC12.ST.Str.general
52 PIOC12.ST.Op.general
53 PIOC13.ST.Str.general
54 PIOC13.ST.Op.general
55 PIOC14.ST.Str.general
56 PIOC14.ST.Op.general
57 PIOC15.ST.Str.general
58 PIOC15.ST.Op.general
59 PIOC16.ST.Str.general
60 PIOC16.ST.Op.general
61 PIOC17.ST.Str.general
62 PIOC17.ST.Op.general
63 PIOC18.ST.Str.general
64 PIOC18.ST.Op.general
65 PIOC19.ST.Str.general
66 PIOC19.ST.Op.general
67 PIOC20.ST.Str.general
Enumeration IEC 61850 report dataset items
