Software Configuration CNF 007 Configuring Barco 3MP2FH Video Driver
Page 142
4. Select the “Adapter” tab and then click on the “List All Modes…” button. Select the resolution
and refresh rate that your CORONIS display panel supports from the dialog box and click
“OK”.
Note: In the Adapter box, the Adapter string shows if this display is the First View or the Second View
on the Imaging Board. Please make a note of this, so that you can arrange the displays in the
correct order later.
5. Drag the heads into the proper position in the window on the
“Settings” tab, so that the
arrangement in the window on the
“Settings” tab matches the physical arrangement of your
configuration.
6. Click
“OK” on the bottom of the Adapter Control Panel. If the “OK” button on the bottom of the
Adapter Control Panel is not visible, press
“CTRL”+“Enter” to select “OK”.
7. Click
“OK” in the “Windows will now apply your new desktop settings” dialog box. Your high
resolution display(s) should now synchronize and display the Windows desktop.
8. Click
“Yes” when asked, “Your desktop has been reconfigured. Do you want to keep these
settings?” To set the resolution of the Second View for you CORONIS display panel, bring up
the
“Display Properties Control Panel” again and select the “Settings” tab.
9. Attach the display you detached in step 2 above, by right clicking on it and selecting
“Attached”.
10. Now repeat steps 3 – 8 above for this display.
If you are using a Quad Head Configuration repeat all of the above steps for the two displays on the
second imaging board.
Note: After installing DualView use the Barco Metheus Configuration Control Panel to verify or
change your system settings.
