Disassembly & Reassembly Procedures DR 001 Video Board Switch Settings
Page 258
n DR 001 Video Board Switch Settings
Section 1: Introduction
This job card describes the various video board switch settings. These switches need to be set
correctly or the system will not boot.
Section 2: Tools Required
u
5 mm cross-head screwdriver
u
5 mm flat-head screwdriver
u
Grounding wristband
u
Small Screwdriver for setting Dip switches
u
Small Needle Nose pliers for removing and installing jumpers
