Hardware Installation IST 002 (A) 1728 x 2304 Portrait Monitor Interconnections
Page 33
n IST 002 (A) 1728 x 2304 Portrait Monitor Interconnections
Section 1: INTRODUCTION
This job card contains the instructions for interconnecting the Workstation to other equipment and
components as part of the installation. Monitor cabling diagrams are provided to show the
interconnection of two or four Barco monitors to the appropriate video board slot positions at the rear
of the computer housing.
Section 2: Prerequisites
The site must be prepared for installation of the workstation. Refer to the Centricity RA600
Workstation Pre-Installation Manual for detailed information.
u
The appropriate line voltage, line frequency, and power supply line cords.
u
Ethernet connection.
u
Appropriate furniture for the Workstation (i.e. desk, chair, etc.)
Section 3: Cabling
Table 3-2 lists the part numbers of interconnecting cables used during installation.
Refer to Illustration 1-3 to see where various connectors are located on the computer housing.
3-1 Components Used During Installation
Caution
!
The maximum magnetic field allowable for installing the Centricity
RA600 Workstation is 1 gauss to ensure proper operation.
