Hardware Installation IST 002 (A) 1728 x 2304 Portrait Monitor Interconnections
Page 34
Table 3-2: Items used for installation of 1728 x 2304 workstation
The Centricity RA600 Workstation should already be configured as per the factory settings. Also, the
operating system software and applications software are installed at the factory. The person
installing the workstation must physically interconnect workstation cables, and then configure the
system using site-specific information (i.e. IP address).
3-2 Line Voltage Selection
Line voltage selection is automatic for the workstation, monitors and most of the peripherals.
3-3 Power Connections
Power cables must be fitted with proper plugs for the country where the workstation is installed. A
distribution strip is supplied with the system.
3-4 Network Connection
The ethernet network connections are made via hubs or switches.
Cable Part
No.
From To Cable Detail
N/A CPU Keyboard Integrated Keyboard Cable
N/A CPU Network 10/100 BaseT Patch Cable
4363102 CPU - Video Board Monitor Cable Monitor Cable to CPU
N/A CPU Mouse Integrated Mouse Cable
4363149 CPU Power Outlet Power Connection, USA
4363149 Monitor(s) Power Outlet Power Connection, USA
N/A CPU VGA port VGA Monitor Service Monitor Tool
