GE Corometrics 129 User Manual

Revision B 120 Series Maternal/Fetal Monitor 4-83
2015590-001
Theory of Operation: Recorder Board
Table 4-30. Power Input Connector J1
Pin Number Signal Name Signal Description
1 +5VM –5 Volt Supply for Motor
2 +5VM –5 Volt Supply for Motor
3 GNDM Motor Ground
4 GNDM Motor Ground
5 GNDH Ground for Head Regulator
6 GNDH Ground for Head Regulator
7 GNDVR Ground for Logic
8 +5VR +5 Volt Supply for Logic
9 +22VH 22 Volt Supply for Head Regulator
10 +22VH 22 Volt Supply for Head Regulator
