7-14 120 Series Maternal/Fetal Monitor Revision B
2015590-001
Calibration: Display Check
Figure 7-1. Monitor Top View
J5
A
MATER
Sp
FECG/M
U
US
U
J6
J4
J10
J1
J7
J2
J1
J2
J9
J1
Connector for
main power
switch harness
Connector for
recorder power
cable
Connector for
recorder output
cable
Connector for
switch panel
cable
Connector for
display cable
Notch in
DSP Board
Nipples for
BP tubes
Clip for MSpO2
ferrite bead (if
MSpO2 installed)
