Revision B 120 Series Maternal/Fetal Monitor 10-7
2015590-001
Strip Chart Recorder Servicing: Field Serviceable Assemblies
Table 10-1. Printhead Adjustments
Adjustment Description
A Set screws loosened to perform a vertical
offset adjustment.
B Hex-head screw loosened to perform a
horizontal offset adjustment.
C Hex-head screw which determines the
vertical offset of a horizontal line. (See
Figure 10-3.)
D Captive hex-head screw which controls
the horizontal offset of a vertical line on
the top grid of the strip chart paper (heart
rate channel).
E Captive hex-head screw which controls
the horizontal offset of a vertical line on
the bottom grid of the strip chart paper
(uterine pressure channel).
