– 53 –
J7
1 - Blk / Wht
2 - Violet / Blk
3 - Yel
4 - Gry
5 - Not Used
6 - Violet
7 - Red
8 - Blk
9 - Orn
GEA00905
PAN_HTR
AUGER
N
DFZ
DFF
OCH
COMMON
WATER
CRUSHER
QC
K5
DEFROST
K3
L1
COMP
DEFR
LINE
2
1
J6
K7
PAN/HTR
K6
WATER
AUGER
K1
C/CR
K2
K4
COMP
J7
DEFROST
COOLING
PRE-CHILL
DOOR
SWITCH
INPUTS
COMPRESSOR
DEFROST
OUTPUTS
AND
OUTPUTS
PROCESSING
UNIT
NOTE: Refer to the Main Control Board Locator Tables in the Diagnostics chapter for more
information.
Main Control Board (120 VAC Side)
