GE GTD75GCPLDG Installation Instructions

Installation Instructions
7
Install a 1/8” NPT plugged tapping to the dryer
gas line shut-off valve for checking gas inlet
pressure.
Install a flare union adapter to the plugged
tapping.
NOTE: Apply pipe compound or PTFE tape
to the threads of the adapter and plugged
tapping.
Attach the flexible metal gas line connector to
the adapter.
B
Tighten the flexible gas line connection, using
two adjustable wrenches.
C
D
Tighten all connections, using two adjustable
wrenches. Do not overtighten.
E
CONNECTING THE DRYER TO THE GAS
SUPPLY (cont.)
Open the gas shut-off valve.
F
Apply pipe compound
or PTFE tape to all
male threads.
Shut-Off
Valve
Plugged
Tapping
CONNECTING THE DRYER TO THE GAS
SUPPLY
Install a female 3/8” NPT elbow at the end of the
dryer gas inlet.
Install a 3/8” flare union adapter to the female
elbow.
IMPORTANT: Use a pipe wrench to securely hold
on to the end of the dryer gas inlet to prevent
twisting the inlet.
NOTE: Apply pipe compound or PTFE tape to the
threads of the adapter and dryer gas inlet.
A
Elbow
Adapter
Items not supplied
Adapter
1/8” NPT
Pipe Plug for
Checking Gas
Inlet Pressure
Shut-Off Valve
Pipe size at
least 1/2”
3/8” NPT
New Metal
Flexible Gas
Line Connector
Apply pipe compound to the
adapter and dryer gas inlet

GE GTD75GCPLDG Specifications

General

Color	gray, diamond gray
Dryer Capactity	7.4 cubic feet
Number of Cycles	14
Cycle Selections	antibacterial, bulky items, damp dry, dewrinkle, extended tumble, jeans, mixed load, quick fluff, sanitize, steam dewrinkle, steam refresh, towels/ sheets
Options	edry, extended tumble, my cycle, delay dry, volume, damp alert
Stackable	no
Venting	no
Temperature Settings	5
Temperature Selections	high, medium, low, extra low, no heat
Temperature Control	no
Delay Start	yes
Child Lock	no
Cycle Signal	yes
Moisture Sensor Option	yes
Steam	yes
Smart Home	yes

Weight and Dimensions

Depth	30 1/2 inches
Height	48 inches
Width	27 inches
