– 59 –
3. Remove the harness connectors from the
connector brackets on the bottom of the tub.
4. Disengage the wire ties securing the harness
to the platform assembly and set the harness
aside. New wire ties are already positioned
on the new harness.
Riser
The riser is a plastic frame that attaches to the
bottom of the cabinet.
The riser was designed to lift the cabinet so the
increased capacity can be accommodated. The
OHYHOLQJOHJVKDYHEHHQUHGHVLJQHGWR¿WLQWRWKH
riser.
Riser Removal
1. To remove/replace the riser, the washer will
need to be laid on its back side.
2. Remove eight 1/4 in. hex head screws that
secures the riser to the bottom of the cabinet.
3. Lift the riser from the cabinet.
Screw
Screw
Screw
Screw
Screw
Screw
Screw
Screw
