– 36 –
Freezer Components
Air Tower Removal
1. Remove shelving.
2. Place a small at blade screwdriver in the air
tower slot and gently push up.
3. Gently push in on either side and lift up. Swing
the bottom outward and slightly pull down for
the air tower tabs to clear the evaporator cover.
4. Remove the air bae from the air duct.
The air bae controls air distribution to the fresh
food section. The air bae is non-adjustable and
must be placed back in the supply duct or cooling
issues will occur.
Evaporator Cover Removal
1. Remove the two 1/4 in. hex head screws.
2. From the fan orice, pull the evaporator cover
outward to remove.
To Next Page
