3-6
6" QuickPanel* ViewBasic, Monochrome, Round Be
z
e
l – September 2010
GFK-2327B
3
To calibrate the touch screen
1.
In the Control Panel, double-tap
Stylus
.
The
Stylus Properti
es
dialog box appears.
2.
Choose the Calibration tab
