Innova 2000 Cardiovascular Imaging System
GE Medical Systems Pre–Installation Manual
REV 5 pim 2337741–100
107
Legend of Illustration:
1 – Innova LC positioner
2 – OMEGA IV Compact patient table
3 – ACAB Cabinet
4 – POSTIT Cabinet
5 – MP Phase IV cabinets
6 – Chiller Coolix 2200 (X–Ray tube housing)
7 – Innova Console
8 – DL Image monitor and keyboard
9 – DL Keypad
10 – DL Flat panel
11 – 17” (43 cm) FFD monitor
12 – Chiller Innova Detector
13 – XT monitor suspension
14 – 21” (53 cm) FFD Monitors put on frame with System Status Display and monitoring screen
15 – Injector on Pedestal
16 – VCR
17 – Bookcase or bookshelves required for Technical Publications and special parts and tools.
18 – GEMnet CRS Station
Note: The phone outlet must be located less than 1 meter (3 feet) from the ACAB
Cabinet (3).
In Examination room
Zone 1 – Intensive lighting needed by operator. Manually cut.
Zone 2 – Variable lighting without specular reflection on Display and monitor screens.
Indirect lighting but preferably from ceiling automatically cut by the Innova 2000 System.
  
Zone 3 – Variable lighting without artifact on Display and monitor screens.
Manually cut.
Lighting level shall be measured on screen and adjusted to a value < to 40 lux:
– avoiding reflections by direct sunlight
– avoiding reflections by indirect sunlight impigning on a reflecting surface
– avoiding reflections from a light source.
CAUTION
