GE Innova 2000 - Illustration

Innova 2000 Cardiovascular Imaging System
GE Medical Systems Pre–Installation Manual
REV 5 pim 2337741–100
64
Illustration 25 – DETECTOR CHILLER DIMENSIONS
141 REF
(5.55)
351
(13.82)
283
(11.14)
20
(0.79)
40
(1.57)
20
(0.79)
311
(12.24)
(4) 6.35 Dia. (0.25)
203
(7.99)
DISPLAY
RESERVOIR CAP
340
(13.39)
359
(14.13)
378
(14.88)
HANDLE
RS232
ON/OFF
IEC 320
WATER
AIR
TOP VIEW
SIDE VIEW
All dimensions are in mm (inches)
CAUTION
The chiller cannot be located more than 3 m (10 ft) below the detector
