2. TRIGGER AN INPUT ON VIDEOFIED PANEL WITH GE INTERLOGIX
PRODUCT APPLICATION NOTEVideofied Upgrade - GE Interlogix
STEP 1: CONFIGURE INPUT ON VIDEOFIED CONTROL PANEL
DATE / TIME
DISARMED LVL: 1
ACCESS LEVEL
4
RIGHT ARROW to ACCESS LEVEL and press YES, RIGHT ARROW to ACCESS
LVL:4 and press YES. When prompted with BADGE OR CODE enter you
installer code + YES
Using the RIGHT ARROW go to CONFIGURATION and press YES.
CONFIGURATION
GENERAL PARAMETERS
PROGRAMMABLE INPUTS
Press YES on GENERAL PARAMETERS
Using the RIGHT ARROW go to PROGRAMMABLE INPUTS and press YES
PROGRAMMABLE INPUT
#
Using the arrow keys press YES on the PROGRAMMABLE INPUT 1
TRANSMISSION
Press YES on TRANSMISSION and choose the desired option using the
arrow keys and YES:
  •Enable-Inputislisteningallthetime
  •Disable-Inputisdisabled
  •OnlyIfArmed-Inputislisteningonlywhensystemisarmed
ALARM MODE
RIGHT ARROW to ALARM MODE and press YES. Use the arrow keys to
choose the desired option followed by YES.
  •Alarm-Eventistransmitted
  •Alarm/End-Eventandrestorearetransmitted
INPUT TYPE
CLOSED
RIGHT ARROW to INPUT TYPE and press YES. Use the arrow keys to choose
Closed and press YES
EVENT TYPE
RIGHT ARROW to EVENT TYPE and press YES. Use the arrow keys to select
the event the panel should report to the central station when the input is
triggered and press YES.
INPUT NAME
RIGHT ARROW to INPUT NAME and press YES. Use the alphanumeric
keypad to define a logical name to the input and press YES.
