Direction 5370626-100, Revision 18 LOGIQ e/LOGIQ e Vet/LOGIQ i/Vivid e Basic Service Manual
4-26 Section 4-3 - General Procedure
4-3-13-2 Activating the probe
The probe activates in the currently-selected operating mode. The probe's default settings for the mode
and selected exam are used automatically.
4-3-13-3 Deactivating the probe
1.) Press the Freeze key.
2.) Gently wipe the excess gel from the face of the probe. (Refer to the Basic User Manual for
complete probe cleaning instructions.)
3.) Carefully slide the probe around the right side of the keyboard, toward the probe holder.
Ensure that the probe is placed gently in the probe holder.
4-3-13-4 Disconnecting the probe
Probes can be disconnected at any time. However, the probe should not be selected as the active
probe.
1.) Unlock the probe latch downward.
2.) Pull the probe and connector straight out of the probe port.
3.) Carefully slide the probe and connector away from the probe port and around the right side of the
keyboard.
4.) Ensure the cable is free.
5.) Be sure that the probe head is clean before placing the probe in its storage box.
4-3-14 Using Cine
4-3-14-1 Activating CINE
Press Freeze, then roll the Trackball to activate CINE. To start CINE Loop playback, press Run/Stop.
To stop CINE Loop playback. press Run/Stop.
4-3-14-2 Quickly Move to Start/End Frame
Press First to move to the first CINE frame; press Last to move to the last CINE frame.
4-3-14-3 Start Frame/End Frame
Press the Start Frame Two-Button Softkey to move to the beginning of the CINE Loop. Adjust the Start
Frame up/down Two-Button Softkey upward to move forward through the CINE Loop. Adjust the
Softkey downward to move backward through the CINE Loop.
Press the End Frame Two-Button Softkey to move to the end of the CINE Loop. Adjust the End Frame
up/down Two-Button Softkey upward to move forward through the CINE Loop. Adjust the Softkey
downward to move backward through the CINE Loop.
4-3-14-4 Adjusting the CINE Loop Playback Speed
Adjust the Loop Speed up/down Two-Button Softkey to increase/decrease the CINE Loop playback
speed.
Take the following precautions with the probe cables: Do not bend. If you have
purchased the cart option, be sure to keep probe cables free from the wheels.
Be careful not to trip on the probe cables if using the device without the optional cart.
