Direction 5370626-100, Revision 18 LOGIQ e/LOGIQ e Vet/LOGIQ i/Vivid e Basic Service Manual
Chapter 5 Components and Functions (Theory) 5-9
5-3-5 Fans
The scanner contains the four fans at the following positions for producing an air flow.
- One fan assy: On the Left side for air flow path A.
- One fan assy: On the Right side for air flow path B.
Figure 5-6 Left & Right Fans
