Direction 5370626-100, Revision 18 LOGIQ e/LOGIQ e Vet/LOGIQ i/Vivid e Basic Service Manual
Chapter 7 Diagnostics/Troubleshooting 7-11
7-5-3-4 Short Text Message
Displays either a starting message or aborting message, as well as the diagnostic completion status.
7-5-3-5 Background Color
Initially gray, the Control Frame background color changes upon completion of a diagnostic to indicate
completion status.
• Fail = Red
• Pass = Green
• Neither pass nor fail = Set back to Gray (for example, final code status is Aborted).
