Direction 5370626-100, Revision 18 LOGIQ e/LOGIQ e Vet/LOGIQ i/Vivid e Basic Service Manual
9-14 Section 9-7 - Bottom Assy
Section 9-7 Bottom Assy (cont’d)
Table 9-5 Bottom Assy
Item
Part
Number Part Name
Replaced
By
Quantity
FRU
LOGIQ e
LOGIQ e Vet
LOGIQ i
Vivid e
300
5148765
Bottom Cover Assy for LOGIQ e R4.x.x / LOGIQ e R5.0.x /
LOGIQ e R5.2.x /LOGIQ e R6.x.x/ LOGIQ e Vet R5.x.x/
R6.x.x
12 x x
5148764 Bottom Cover Assy for Vivid e R4.x.x / LOGIQ e R4.x.x 1 2 x x
5213129 Bottom Cover Assy for Vivid e R5.x.x / Vivid e R6.x.x 1 2 x
5182370 Bottom Cover Assy for LOGIQ i R4.x.x / LOGIQ i R5.x.x 1 2 x
5422185
Bottom Cover Assy for LOGIQ e R7.x.x / Vivid e R5.x.x / Vivid
e R6.x.x / LOGIQ e Vet R6.0.5 or above/ LOGIQ e Vet R7.x.x
1 2 x x x
301
2406640 TMST Board 2406640-3R 1 1 x x x x
2406640-2 TMST Board 2406640-3R 1 1 x x x x
2406640-3 TMST Board 2406640-3R 1 1 x x x x
2406640-4
TMST Board for LOGIQ e R7.x.x/LOGIQ e Vet R7.x.x /
LOGIQ e R5.2.3 / LOGIQ e R6.0.5
11 x x
301A
2406640-3R
TMST PWA for LOGIQ e R4.x.x / LOGIQ e R5.x.x / LOGIQ e
R6.x.x /Vivid e R4.x.x / Vivid e R5.x.x / LOGIQ i R4.x.x /
LOGIQ i R5.x.x / LOGIQ e Vet R5.x.x/ LOGIQ e Vet R6.x.x
1 1 x x x x
302
2404903
TX64 Board for LOGIQ e R4.x.x / LOGIQ e R5.x.x / Vivid e
R4.x.x / Vivid e R5.x.x / LOGIQ i R4.x.x / LOGIQ i R5.x.x /
LOGIQ e Vet
5458245 1 1 x x x x
302A
2404903-2
TX64 Board for LOGIQ e R4.x.x / LOGIQ e R5.x.x / Vivid e
R4.x.x / Vivid e R5.x.x / LOGIQ i R4.x.x / LOGIQ i R5.x.x /
LOGIQ e Vet
5458245 1 1 x x x x
302B
2404903-3
TX64 Board for LOGIQ e R4.x.x / LOGIQ e R5.x.x / Vivid e
R4.x.x / Vivid e R5.x.x / LOGIQ i R4.x.x / LOGIQ i R5.x.x /
LOGIQ e Vet
5458245 1 1 x x x x
302C
2404903-6
TX64 Board for LOGIQ e R6.x.x / Vivid e R6.x.x / LOGIQ e
Vet
5458245 1 1 x x x
302D
5458245
TX64 Board for LOGIQ e R4.x.x LOGIQ e R5.x.x/ LOGIQ e
R6.x.x/Vivid e R4.x.x/ Vivid e R5.x.x/ Vivid e R6.x.x /LOGIQ i
R4.x.x/ LOGIQ i R5.x.x/ LOGIQ e Vet R6.x.x (current version)
11 x x xx
321
5436388 TX64 Board for LOGIQ e Vet R7.x.x 1 1 x
321A
5436388 TX64 Board for LOGIQ e R7.x.x 5436388-S 1 1 x
321B
5436388-S TX64 Board for LOGIQ e R7.x.x 1 1 x
303
2404906 RX64 Board 2404906-2 1 1 x x x x
