Direction 5370626-100, Revision 18 LOGIQ e/LOGIQ e Vet/LOGIQ i/Vivid e Basic Service Manual
9-16 Section 9-7 - Bottom Assy
307A
5392210-3
U7500 CPU kits only for LOGIQ e R6.x.x / Vivid e R6.x.x/
LOGIQ e Vet 6.x.x
1 1 x x x
5392210-6
U7500 CPU kits for LOGIQ e 7.x.x (Update BIOS)/ LOGIQ e
Vet R7.x.x
1 1 x
308
5159620 512MB DDR Memory 1 1 x x x x
5392214 1G DDR2 Memory 1 1 x x x x
309
5162038-3
Charger Board and Cable Kits for LOGIQ e R5.0.x / LOGIQ e
R5.2.x /LOGIQ e R6.x.x/ LOGIQ e Vet / Vivid e R5.x.x / Vivid
e R6.x.x / LOGIQ i R5.x.x
5162038-3R 1 2 x x x x
5162038-2
Charger Board and Cable Kits for LOGIQ e R4.x.x / Vivid e
R4.x.x / LOGIQ i R4.x.x
5162038-3R 1 2 x x x
309A
5162038-3R Charger PWA 1 2 x x x x
310
5148768 Left FAN Assy (2 Fans) 1 1 x x x x
5173403-3 Right FAN Assy (2 Fans) 1 1 x x x x
311
5155166 LCD and Handle Hinge kits 1 1 x x x x
312
2406733 TMST2TX64 Assy 2406733-R 1 2 x x x x
312A
2406733-R TMST2TX64 Assy 1 2 x x x x
313
5154937
Handle Assy for LOGIQ e R4.x.x / LOGIQ e R5.0.x /LOGIQ e
R5.2.X/LOGIQ e R6.x.x / LOGIQ e Vet / Vivid e R4.x.x /
LOGIQ i R4.x.x / LOGIQ i R5.x.x
1 2 x x x x
5234933 Handle Assy for Vivid R5.x.x / Vivid e R6.x.x 1 2 x
314
5154486 Screw Kits 1 2 x x x x
315
5154731 Rubber Kits 1 2 x x x x
316
5255230 80G HDD without Program Assy
5477476,
5478478,
5478479,
5478480
11 x x xx
5427957-2 Western Digital 500G SATA Hard Drive 1 1 x x x x
5148772 HDD Assy for LOGIQ e R4.x.x 5478478 1 1 x
5190005 HDD Assy for LOGIQ i R4.x.x / LOGIQ i R5.x.x 5478478 1 1 x
5255231-2 160G HDD without Program Assy
5477476,
5478478,
5478479,
5478480
1 1 x x x x
5174862-5 HDD Assy for Vivid e R4.x.x 5478478 1 1 x
Table 9-5 Bottom Assy
Item
Part
Number
Part Name
Replaced
By
Quantity
FRU
LOGIQ e
LOGIQ e Vet
LOGIQ i
Vivid e
