GE
Direction 5370626-100, Revision 18 LOGIQ e/LOGIQ e Vet/LOGIQ i/Vivid e Basic Service Manual
Chapter 3 System Setup 3-5
Section 3-2 Receiving and Unpacking the Equipment (cont’d)
3.) Take out the Paper pad.
4.) Take out console together with 2 interleavers from console package.
5.) Take out the interleavers beside Accessories Package.
6.) Take out Accessories Package.
Figure 3-2 Unpacking the equipment
Do not lift the unit by the rubber band. Equipment damage may result.
Paper Pad
Console and interleavers
Console Package
Accessories Package
To Next Page
