A.19
M-PACT Plus
M-PACT Accessories
A
B
C
X
Auxiliary switches
The M-PACT Plus circuit breaker is equipped with 5 NO and
3 NC auxiliary switches as standard. Maximum number of
contacts is 8, for alternative confi gurations please contact
for availability.
Mechanical operation counter
Easily fi tted, this useful accessory may be specifi ed for use
with either manual or motor charged M-PACT Plus circuit
breakers.
It is clearly visible through the front panel, and the counter
provides an accurate record of the cumulative number of
complete breaker closing operations.
Key interlock facility
Ready-to-fi t interlocking device: Ronis, for installation between
separate circuit breakers, available in kit form.
This valuable safeguard ensures that a circuit breaker cannot
be closed unless the dedicated key has been inserted and
secured within the lock.
Lock and key types
Ronis: Type 1104B lock with standard key, 1/4" turn rotation
to trap the key, compulsory spindle size.
Cassette main terminal adaptors
Combinations of rear and front access connections possible
for entire range. Tested and approved from 50 to 80kA.
To simplify main busbar or cable termination, M-PACT Plus
provides a full range for rear and/or front access connection.
Bolt-on adaptor kits can be fi tted easily to suit either horizontal
or vertical connections.
