GE M-Pact Plus - Specify on the Order

B.3
M-PACT Plus
Specify on the order
A
B
C
X
1. Customer Name 2. Project Name 3. Quantity
Specify on the Order
Code M
     
-
       
Voltage (Ue)

415V

690V
1. Device

TypeS 50kA

TypeN 65kA

TypeH 80kA
2. Rating

400A

630A

800A

1000A

1250A

1600A

2000A

2500A

3200A

4000A
3. Number of Poles

3 Pole

4Pole Left Neutral

4Pole Right Neutral
4. System

3 phase 3 wire

3 phase 4 wire
5. Frequency

50Hz

60Hz
6. Type Connections Top&Bottom

Fix

Front

Horizontal

Vertical

Withdrawable

Front

Horizontal

Vertical

Moving portion only

Cassette only

Front

Horizontal

Vertical
7. Protection

Non automatic

MPRO 27

MPRO 50L/H

MPRO 27 with GF
8. MPRO Optional
Features

Mechanical Operation Counter

Mechanical Trip Alarm Switch (1NO)

Portable Test Unit Auxillary Power Unit

110V AC/DC

220V AC/DC
Auxillary Contactor

5NC+3NC

4NC+4NC
9. Control Voltage MOP CC ST UV UVTD
24/30V DC

 
48V DC
    
60V DC

110/130V DC
   
110/130V AC
   
220/250V DC
 
220/250V AC
    
380/440V AC
    

Spring Charge Signal (1NO)
10. Carriage switch

Factory fi tted

Loose kit
11. Interlocks Door interlock

Left Hand Door Interlock

Right Hand Door Interlock

Ronis Cassette Key interlock

Ronis Breaker Key interlock

Lock A

Lock B

Lock C

Lock D

Circuit breaker misinsertion interlock
Cable Interlock

Type A 2 way

Type B 1 from 3 way

Type C 2 from 3 way

Type D 1 from 3 way
Cable Length required (in centimeters)

160

200

300
12. Miscellaneous

IP54 Door panel

ACB Lifting Truck
13. Special requirements (please Specify any improtant instructions)
