GE Marquette MAC 5000

Revision B 4-11
Troubleshooting: CPU PCB Input/Output Signals
MAC 5000 resting ECG analysis system
2000657-002
Power Supply/Motor
(J11)
Pin No. Signal
1 Motor Encoder B
2 5V Power
3 Motor A
4 Motor Encoder A
5 Ground
6Motor B
7 NC
8 28V Power
9 Ground
10 Battery Charge LED
11 28V Power
12 Ground
13 Door Open Detect
14 Ground
