Revision B 6-9
Parts Lists and Drawings: 900769-001F Generic Assembly
MAC 5000 resting ECG analysis system
2000657-002
900769-001F Generic Assembly
Find
Num
Item Description Item Number Qty
1 SCREW MACHINE, PNHD, M2.6A X 3MM 2001785-001 2
2 COVER, TOP MAC 5000 416001-001 1
3 DISK DRIVE 3.5IN LAPTOP FLOPPY 2001377-001 1
4 BUTTON BATTERY MAC SERIES 416298-001 1
5 BUTTON, WRITER MAC SERIES 416406-001 1
6 DRIVE COVER MAC 5000 417468-002 1
7 PANEL CONNECTOR, MAC 5000 417471-001 1
8 BUTTON PANEL MAC 5000 417471-002 1
9 LIGHTPIPE MAC 5000 421178-001 1
10 M3 X 8MM TORX SEMS 418545-001 29
11 STOP PANEL BUTTON MAC SERIES 419210-001 1
12 SPRING BATTERY MAC SERIES 419752-001 1
13 SPRING, BAT. BUTTON MAC 419753-001 1
15 PAD BOTTOM MAC SERIES 419755-001 2
16 INSULATOR BD MAC SERIES 419759-001 1
17 CONN VERT MINI-DRAWER 14P J 419957-001 1
18 PRINTER THERMAL MAC SERIES 421108-003 1
19 BRACKET FLOPPY MAC SERIES 421110-002 1
20 PAD FLOPPY MAC SERIES 421193-001 1
21 KIT SHIPPING CARTON MAC 5000 421783-001 1
22 ADHESIVE LIGHTPIPE MAC SERIES 421195-001 1
23 CABLE COILED ASSY HOST AM11X 700657-001 1
24 PCB MAC 5000 CPU 801212-003 1
25 PCB MAC 5000 BATTERY TRANS 801220-001 1
26 PCB LED BOARD MAC 5000 801222-001 1
27 BATTERY PACK ASSY MAC PAC 900770-001 1
28 ASSY DISPLAY MAC 5000 421114-002 1
30 ASSY POWER SUPPLY MAC 5000 421117-001 1
31 LABEL SET MAC 5000 417567-001 1
33 HARNESS PS/LED/MOTOR 700645-001 1
34 WASH NYL .28 OD .12 ID .03 THK 4550-014 1
35 HARNESS PWR TO CPU BD 700682-001 1
36 HARNESS GROUND MAG MAC 5000 700686-001 1
37 CABLE ASSY PRTHD/SENSOR W/O FER 700687-002 1
38 CABLE FLAT RIBBON FLOPPY DRIVE 700688-001 1
39 LABEL SET MAC5000 BOTTOM COVER 420016-001 1
40 WASHER FLAT SS #4 4520-004 5
41 BAG POLY 22X22X47IN ANTI-STAT 421883-001 1
To Next Page
