Page #77 background imageLoading...
Page #77 background image
3 SETUP AND USE Setpoints, Pg. 7
3-38
12
OVERVOLTAGE ALARM LEVELOVERVOLTAGE ALARM LEVEL
O/V ALARM = XXX %VTO/V ALARM = XXX %VT
This setpoint sets the threshold for the overvoltage alarm condition as a percentage of VT primary.
The alarm level programmed in this setpoint is compared to the average voltage received from the me-
ter.
101–115% (increments of 1) or OFF.
Factory Value = OFF.
13
OVERVOLTAGE ALARM TIMEOVERVOLTAGE ALARM TIME
DELAY = XXX SECDELAY = XXX SEC
This setpoint sets the time that an overvoltage alarm condition must persist in order to facilitate an
alarm.
The alarm level programmed in this setpoint is compared to the average voltage received from the me-
ter.
1-255 seconds (increments of 1)
Factory Value = 10
14
OVERVOLTAGE TRIP LEVELOVERVOLTAGE TRIP LEVEL
O/V TRIP = XX %VTO/V TRIP = XX %VT
This setpoint sets the threshold for the overvoltage trip condition as a percentage of VT primary.
The trip level programmed in this setpoint is compared to the average voltage received from the meter.
101–115 % (increments of 1) or OFF
Factory Value = OFF
15
O/V TRIP TIME DELAYO/V TRIP TIME DELAY
TIME DELAY = XXX SECTIME DELAY = XXX SEC
This setpoint sets the time that an overvoltage trip condition must persist in order to facilitate a trip.
1-255 seconds (increments of 1)
Factory Value = 5
16
BLOCK PF PROTECTIONBLOCK PF PROTECTION
ON START? XXXON START? XXX
When programmed to “YES”, the “PF PROTECTION DELAY” setpoint is not shown. Instead, the
“BLOCK PF ALARM & TRIP ON START” setpoint is shown.
YES - “BLOCK PF ALARM & TRIP ON START BY” is shown and may be enabled; “PF PROTECTION
NO - “BLOCK PF ALARM & TRIP ON START BY” is not shown; “PF PROTECTION DELAY” is shown
and may be enabled.
Factory Value = NO
