GE MULTILIN 269 MOTOR MANAGEMENT RELAY Series User Manual

3 SETUP AND USE Setpoints, Pg. 7
3-40
23
POWER FACTOR LAGPOWER FACTOR LAG
TRIP LEVEL = X.XXTRIP LEVEL = X.XX
This setpoint is used to set the power factor "lag" trip threshold level for a power factor trip condition.
0.05-0.99 (increments of 0.01) or OFF
Factory Value = OFF
24
POWER FACTOR TRIPPOWER FACTOR TRIP
TIME DELAY = XXXTIME DELAY = XXX
This setpoint is used to set the time delay that a power factor trip condition must persist for in order to
facilitate a trip.
1-255 seconds (increments of 1)
Factory Value = 5
25
POSITIVE KVAR ALARMPOSITIVE KVAR ALARM
LEVEL = +XXXXX KVARSLEVEL = +XXXXX KVARS
This setpoint is used to set the positive kvar limit threshold for a kvar alarm condition.
100-25000 (increments of 100) or OFF
Factory Value = OFF
26
NEGATIVE KVAR ALARMNEGATIVE KVAR ALARM
LEVEL = -XXXXX KVARSLEVEL = -XXXXX KVARS
This setpoint is used to set the negative kvar limit threshold for a kvar alarm condition.
100-25000 (increments of 100) or OFF
Factory Value = OFF
27
KVAR ALARMKVAR ALARM
TIME DELAY = XXX SECTIME DELAY = XXX SEC
This setpoint is used to set the time that a KVAR alarm condition must persist for in order to facilitate an
alarm.
1-255 seconds (increments of 1)
Factory Value = 5
28
ENABLE VOLTAGE PHASEENABLE VOLTAGE PHASE
REVERSAL? XXXREVERSAL? XXX
This setpoint is used to enable or disable the phase reversal trip feature as detected from the meter
monitoring the line voltages.
YES - enable voltage phase reversal
NO - disable voltage phase reversal
