GEK-113000T F650 Digital Bay Controller 5-3
5 BOOTCODE AND FIRMWARE UPGRADE 5.1 INTRODUCTION
5
If the relay is connected to an Ethernet network, check that the IP address is unique in order to avoid collisions.
In the case of relay that has upgraded previously its Bootcode (Sections 2), the IP address already has been assigned in
the previous process (see Figure 5–14:).
For example, if the relay settings are:
IP address: 192.168.37.177,
Netmask: 255.255.255.0 and
Gateway: 192.168.37.10.
The computer settings have to follow the pattern:
IP address: 192.168.37.XXX
Netmask: 255.255.255.0 and
Gateway: 192.168.37.10 (if desired).
XXX is a number between 0 and 255 that is not assigned to any other device to avoid collisions.
If there are not TCP/IP settings according to this pattern in the computer, it should be added (in order to communicate with
the relay) following these steps:
Go to the Control Panel of the computer and select the Network option (the name of this option may depend on the PC
boot code).
Figure 5–2: NETWORK IN CONTROL PANEL
In Network, enter in Protocols, select TCP/IP protocol and click on P
roperties.
Gateway IP Oct4 10 [0 : 255]
