12–8 MULTILINK ML2400 ETHERNET COMMUNICATIONS SWITCH – INSTRUCTION MANUAL
SPANNING TREE PROTOCOL (STP) CHAPTER 12: SPANNING TREE PROTOCOL (STP)
Example 12-4: Configuring STP parameters
ML2400(stp)##
show stp config
STP CONFIGURATION
-----------------
Spanning Tree Enabled(Global) : NO
Spanning Tree Enabled(Ports) : YES, 9,10,11,12,13,14,15,16
Protocol : Normal STP
Bridge ID : 80:00:00:20:06:25:ed:80
Bridge Priority : 32768
Bridge Forward Delay : 15
Bridge Hello Time : 2
Bridge Max Age : 20
Root Port : 0
Root Path Cost : 0
Designated Root : 80:00:00:20:06:25:ed:80
Designated Root Priority : 32768
Root Bridge Forward Delay : 15
Root Bridge Hello Time : 2
Root Bridge Max Age : 20
RSTP CONFIGURATION
-----------------
Rapid STP/STP Enabled(Global) : NO
ML2400(stp)## show stp ports
STP Port Configuration
--------------------------------------------------------------------------------------
Port# Type Priority Path Cost State Des. Bridge Des. Port
--------------------------------------------------------------------------------------
09 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:09
10 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:0a
11 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:0b
12 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:0c
13 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:0d
14 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:0e
15 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:0f
16 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:10
ML2400(stp)## stp enable
Successfully set the STP status
(continued on next page)
