13–12 MULTILINK ML2400 ETHERNET COMMUNICATIONS SWITCH – INSTRUCTION MANUAL
RAPID SPANNING TREE PROTOCOL CHAPTER 13: RAPID SPANNING TREE PROTOCOL
Configuring RSTP (continued)
ML2400(rstp)##
show stp ports
RSTP Port Configuration
--------------------------------------------------------------------------------------
Port# Type Priority Path Cost State Des. Bridge Des. Port
--------------------------------------------------------------------------------------
09 TP(10/100) 128 2000000 Forwarding 80:00:00:20:06:25:ed:89 00:09
10 TP(10/100) 128 2000000 Disabled 00:0a
11 TP(10/100) 128 2000000 Disabled 00:0b
12 TP(10/100) 128 2000000 Disabled 00:0c
13 TP(10/100) 128 200000 Forwarding 80:00:00:20:06:25:ed:89 00:0d
14 TP(10/100) 128 2000000 Disabled 00:0e
15 TP(10/100) 128 2000000 Disabled 00:0f
16 TP(10/100) 128 2000000 Disabled 00:10
ML2400(rstp)## priority port=13 value=100
ML2400(rstp)##
show stp ports
RSTP Port Configuration
--------------------------------------------------------------------------------------
Port# Type Priority Path Cost State Des. Bridge Des. Port
--------------------------------------------------------------------------------------
09 TP(10/100) 128 2000000 Forwarding 80:00:00:20:06:25:ed:89 00:09
10 TP(10/100) 128 2000000 Disabled 00:0a
11 TP(10/100) 128 2000000 Disabled 00:0b
12 TP(10/100) 128 2000000 Disabled 00:0c
13 TP(10/100) 100 200000 Forwarding 80:00:00:20:06:25:ed:89 00:0d
14 TP(10/100) 128 2000000 Disabled 00:0e
15 TP(10/100) 128 2000000 Disabled 00:0f
16 TP(10/100) 128 2000000 Disabled 00:10
ML2400(rstp)## cost port=13 value=250000
ML2400(rstp)##
show stp ports
RSTP Port Configuration
--------------------------------------------------------------------------------------
Port# Type Priority Path Cost State Des. Bridge Des. Port
--------------------------------------------------------------------------------------
09 TP(10/100) 128 2000000 Forwarding 80:00:00:20:06:25:ed:89 00:09
10 TP(10/100) 128 2000000 Disabled 00:0a
11 TP(10/100) 128 2000000 Disabled 00:0b
12 TP(10/100) 128 2000000 Disabled 00:0c
13 TP(10/100) 100 250000 Forwarding 80:00:00:20:06:25:ed:89 00:0d
14 TP(10/100) 128 2000000 Disabled 00:0e
15 TP(10/100) 128 2000000 Disabled 00:0f
16 TP(10/100) 128 2000000 Disabled 00:10
ML2400(rstp)## port port=9 status=disable
(continued on next page)
