CHAPTER 13: RAPID SPANNING TREE PROTOCOL RAPID SPANNING TREE PROTOCOL
MULTILINK ML2400 ETHERNET COMMUNICATIONS SWITCH – INSTRUCTION MANUAL 13–13
Configuring RSTP (continued)
ML2400(rstp)##
show stp ports
RSTP Port Configuration
--------------------------------------------------------------------------------------
Port# Type Priority Path Cost State Des. Bridge Des. Port
--------------------------------------------------------------------------------------
09 TP(10/100) 128 2000000 No STP 00:09
10 TP(10/100) 128 2000000 Disabled 00:0a
11 TP(10/100) 128 2000000 Disabled 00:0b
12 TP(10/100) 128 2000000 Disabled 00:0c
13 TP(10/100) 100 250000 Forwarding 80:00:00:20:06:25:ed:89 00:0d
14 TP(10/100) 128 2000000 Disabled 00:0e
15 TP(10/100) 128 2000000 Disabled 00:0f
16 TP(10/100) 128 2000000 Disabled 00:10
ML2400(rstp)## port port=9 status=enable
ML2400(rstp)##
show stp ports
RSTP Port Configuration
--------------------------------------------------------------------------------------
Port# Type Priority Path Cost State Des. Bridge Des. Port
--------------------------------------------------------------------------------------
09 TP(10/100) 128 2000000 Forwarding 80:00:00:20:06:25:ed:89 00:09
10 TP(10/100) 128 2000000 Disabled 00:0a
11 TP(10/100) 128 2000000 Disabled 00:0b
12 TP(10/100) 128 2000000 Disabled 00:0c
13 TP(10/100) 100 250000 Forwarding 80:00:00:20:06:25:ed:89 00:0d
14 TP(10/100) 128 2000000 Disabled 00:0e
15 TP(10/100) 128 2000000 Disabled 00:0f
16 TP(10/100) 128 2000000 Disabled 00:10
ML2400(rstp)## timers forward-delay=20 hello=5 age=30
Successfully set the bridge time parameters
ML2400(rstp)## show stp config
RSTP CONFIGURATION
-----------------
Rapid STP/STP Enabled(Global) : YES
RSTP/STP Enabled Ports : 9,10,11,12,13,14,15,16
Protocol : Normal RSTP
Bridge ID : 80:00:00:20:06:25:ed:89
Bridge Priority : 0
Bridge Forward Delay : 20
Bridge Hello Time : 05
Bridge Max Age : 30
Root Port : 0
Root Path Cost : 0
Designated Root : 80:00:00:20:06:25:ed:89
Designated Root Priority : 0
Root Bridge Forward Delay : 20
Root Bridge Hello Time : 05
Root Bridge Max Age : 30
Topology Change Count : 0
Time Since Topology Chg : 567
ML2400(rstp)## exit
ML2400#
