12–10 MULTILINK ML2400 ETHERNET COMMUNICATIONS SWITCH – INSTRUCTION MANUAL
SPANNING TREE PROTOCOL (STP) CHAPTER 12: SPANNING TREE PROTOCOL (STP)
Configuring STP parameters (continued)
RSTP CONFIGURATION
-----------------
Rapid STP/STP Enabled(Global) : NO
ML2400(stp)## priority port=13 value=20
Successfully set the priority for port 13
ML2400(stp)## show stp ports
STP Port Configuration
--------------------------------------------------------------------------------------
Port# Type Priority Path Cost State Des. Bridge Des. Port
--------------------------------------------------------------------------------------
09 TP(10/100) 128 100 Forwarding 80:00:00:20:06:25:ed:80 80:09
10 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:0a
11 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:0b
12 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:0c
13 TP(10/100) 20 19 Forwarding 80:00:00:20:06:25:ed:80 80:0d
14 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:0e
15 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:0f
16 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:10
ML2400(stp)## cost port=13 value=20
Setting cost for STP...Successfully set the path cost for port 13
ML2400(stp)## show stp ports
STP Port Configuration
--------------------------------------------------------------------------------------
Port# Type Priority Path Cost State Des. Bridge Des. Port
--------------------------------------------------------------------------------------
09 TP(10/100) 128 100 Forwarding 80:00:00:20:06:25:ed:80 80:09
10 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:0a
11 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:0b
12 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:0c
13 TP(10/100) 20 20 Forwarding 80:00:00:20:06:25:ed:80 80:0d
14 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:0e
15 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:0f
16 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:10
ML2400(stp)## port port=9 status=disable
Successfully set the STP status for port 9
ML2400(stp)## show stp ports
STP Port Configuration
--------------------------------------------------------------------------------------
Port# Type Priority Path Cost State Des. Bridge Des. Port
--------------------------------------------------------------------------------------
10 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:0a
11 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:0b
12 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:0c
13 TP(10/100) 20 20 Forwarding 80:00:00:20:06:25:ed:80 80:0d
14 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:0e
15 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:0f
16 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:10
(continued on next page)
Since port 9 does not participate in
STP, it is not listed here. Any changes
made to STP parameters on port 9 will
be ignored
