13–6 MULTILINK ML2400 ETHERNET COMMUNICATIONS SWITCH – INSTRUCTION MANUAL
RAPID SPANNING TREE PROTOCOL CHAPTER 13: RAPID SPANNING TREE PROTOCOL
Example 13-1: Enabling RSTP and reviewing the RSTP variables
ML2400#
rstp
ML2400(rstp)##
show stp config
RSTP CONFIGURATION
-----------------
Rapid STP/STP Enabled(Global) : NO
ML2400(rstp)## rstp enable
Successfully set the RSTP status
ML2400(rstp)## show active-stp
Current Active Mode: RSTP.
RSTP is Enabled.
ML2400(rstp)## show stp config
RSTP CONFIGURATION
-----------------
Rapid STP/STP Enabled(Global) : YES
RSTP/STP Enabled Ports : 9,10,11,12,13,14,15,16
Protocol : Normal RSTP
Bridge ID : 80:00:00:20:06:25:ed:89
Bridge Priority : 0
Bridge Forward Delay : 15
Bridge Hello Time : 2
Bridge Max Age : 20
Root Port : 0
Root Path Cost : 0
Designated Root : 80:00:00:20:06:25:ed:89
Designated Root Priority : 0
Root Bridge Forward Delay : 15
Root Bridge Hello Time : 2
Root Bridge Max Age : 20
Topology Change Count : 0
Time Since Topology Chg : 12
ML2400(rstp)## show stp config
RSTP CONFIGURATION
-----------------
Rapid STP/STP Enabled(Global) : YES
RSTP/STP Enabled Ports : 9,10,11,12,13,14,15,16
Protocol : Normal RSTP Ring Only Mode
Bridge ID : 80:00:00:20:06:25:ed:89
Bridge Priority : 0
Bridge Forward Delay : 15
Bridge Hello Time : 2
Bridge Max Age : 20
Root Port : 0
Root Path Cost : 0
Designated Root : 80:00:00:20:06:25:ed:89
Designated Root Priority : 0
Root Bridge Forward Delay : 15
Root Bridge Hello Time : 2
Root Bridge Max Age : 20
Topology Change Count : 0
Time Since Topology Chg : 12
