NX-8 Control
49
LOC PG DESCRIPTION DEFAULT DATA
PARTITION 5, FEATURE AND REPORTING SELECTION
Segment #1 Segment #2 Segment #3
99 33
1
2
3
4
5
6
7
8
Quick Arm
Re-Exit
Auto Bypass
Silent Panic
Audible Panic
Auxiliary 1
Auxiliary 2
Multi Keypress Tamper
1
2
3
4
5
6
7
8
LED Extinguish enable
Require user code for bypassing zones
Bypass sounder alert
AC Power/Low Battery sounder alert
Enables Bypass toggle
Enables Silent Auto Arm
Enables Automatic Instant
Reserved
1
2
3
4
5
6
7
8
Open/Close
Bypass
Restore
Trouble
Tamper
Cancel
Recent Closing
Exit Error
PARTITION 5, ENTRY/EXIT TIMERS
Segment #1 (Entry Time #1)
0 _
Segment #2 (Exit Time #1)
0 _
Segment #3 (Entry Time #2)
0 _
100
33
Segment #4 (Exit Time #2)
0 _
101 34 PARTITION 6, ACCOUNT CODE 10-10-10-10-10-10 _ _ _ _ _ _
PARTITION 6, FEATURE AND REPORTING SELECTION
Segment #1 Segment #2 Segment #3
102 34
1
2
3
4
5
6
7
8
Quick Arm
Re-Exit
Auto Bypass
Silent Panic
Audible Panic
Auxiliary 1
Auxiliary 2
Multi Keypress Tamper
1
2
3
4
5
6
7
8
LED Extinguish enable
Require user code for bypassing zones
Bypass sounder alert
AC Power/Low Battery sounder alert
Enables Bypass toggle
Enables Silent Auto Arm
Enables Automatic Instant
Reserved
1
2
3
4
5
6
7
8
Open/Close
Bypass
Restore
Trouble
Tamper
Cancel
Recent Closing
Exit Error
PARTITION 6, ENTRY/EXIT TIMERS
Segment #1 (Entry Time #1)
0 _
Segment #2 (Exit Time #1)
0 _
Segment #3 (Entry Time #2)
0 _
103
34
Segment #4 (Exit Time #2)
0 _
104 34 PARTITION 7, ACCOUNT CODE 10-10-10-10-10-10 _ _ _ _ _ _
PARTITION 7, FEATURE AND REPORTING SELECTION
Segment #1 Segment #2 Segment #3
105 34
1
2
3
4
5
6
7
8
Quick Arm
Re-Exit
Auto Bypass
Silent Panic
Audible Panic
Auxiliary 1
Auxiliary 2
Multi Keypress Tamper
1
2
3
4
5
6
7
8
LED Extinguish enable
Require user code for bypassing zones
Bypass sounder alert
AC Power/Low Battery sounder alert
Enables Bypass toggle
Enables Silent Auto Arm
Enables Automatic Instant
Reserved
1
2
3
4
5
6
7
8
Open/Close
Bypass
Restore
Trouble
Tamper
Cancel
Recent Closing
Exit Error
PARTITION 7, ENTRY/EXIT TIMERS
Segment #1 (Entry Time #1)
0 _
Segment #2 (Exit Time #1)
0 _
Segment #3 (Entry Time #2)
0 _
106 34
Segment #4 (Exit Time #2)
0 _
107 34 PARTITION 8, ACCOUNT CODE 10-10-10-10-10-10 _ _ _ _ _ _

GE NX-1308E - Caddx 8 Zone LED Keypad Specifications

Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP
auxiliary power with NX-320E power supply	12 VDC Regulated 2 AMPS
LED keypad current draw	130 mA max.
LED keypad zones normal w/o sounder	55 mA
NX-148E LCD keypad current draw	110 mA max.
NX-148E LCD keypad w/o sounder	75 mA

Operating Environment

operating temperature	32 to 120 degrees F

Loop Specifications

standard loop resistance	300 Ohms Maximum
2-wire smokes resistance	30 Ohms Maximum
loop response	Selectable 50mS or 500mS

Weight and Dimensions

LED keypad width	6.4"
LED keypad height	4.0"
LED keypad depth	1.1"
NX-148E LCD keypad width	6.4"
NX-148E LCD keypad height	5.3"
NX-148E LCD keypad depth	1.0"
metal enclosure width	11.25"
metal enclosure height	11.25"
metal enclosure depth	3.50"
shipping weight	9 lbs.
