NX-8 Control
50
LOC PG DESCRIPTION DEFAULT DATA
PARTITION 8, FEATURE AND REPORTING SELECTION
Segment #1 Segment #2 Segment #3
108 34
1
2
3
4
5
6
7
8
Quick Arm
Re-Exit
Auto Bypass
Silent Panic
Audible Panic
Auxiliary 1
Auxiliary 2
Multi Keypress Tamper
1
2
3
4
5
6
7
8
LED Extinguish enable
Require user code for bypassing zones
Bypass sounder alert
AC Power/Low Battery sounder alert
Enables Bypass toggle
Enables Silent Auto Arm
Enables Automatic Instant
Reserved
1
2
3
4
5
6
7
8
Open/Close
Bypass
Restore
Trouble
Tamper
Cancel
Recent Closing
Exit Error
109 35 PARTITION 8, ENTRY/EXIT TIMERS
Segment #1 (Entry Time #1) 0 _
Segment #2 (Exit Time #1) 0 _
Segment #3 (Entry Time #2) 0 _
Segment #4 (Exit Time #2) 0 _
110 35 ZONE TYPE 1 ALARM EVENT CODE 8 _
111 35 ZONE TYPE 1 CHARACTERISTIC SELECT
Segment #1 (Circle numbers to program)
1
2
3
4
Fire (enable for fire zone).
24 Hour (enable for non-fire 24 hour
zone).
Keyswitch zone.
Follower (enable for burg zones that are
instant during non-entry times).
5
6
7
8
Delay 1 zone (enable to follow Timer 1 Entry/Exit
times).
Delay 2 zone (enable to follow Timer 2 Entry / Exit
times).
Interior (Enable for auto bypass or stay arming).
Local Only (enable if zone is not to be reported).
Segment #2 (Circle numbers to program)
1
2
3
4
Keypad audible on alarm.
Yelping siren on alarm.
Temporal siren on alarm.
Chime.
5
6
7
8
Bypassable.
Group Shunt.
Force armable.
Entry Guard.
Segment #3 (Circle numbers to program)
1
2
3
4
Fast Loop Response.
Double End of Line Tamper zone.
Trouble zone (Day zone).
Cross Zone.
5
6
7
8
Dialer Delay zone.
Swinger zone.
Restore reporting.
Listen-In.
THE DEFAULTS LISTED IN THE ODD NUMBERED LOCATIONS BELOW REPRESENT THE THREE SEGMENTS OF
EACH OF THOSE LOCATIONS. USE THE THREE SEGMENT CHARTS FROM LOCATION 111 TO UNDERSTAND
THESE DEFAULTS.
112 35 ZONE TYPE 2 ALARM EVENT CODE 2 _
113 35 ZONE TYPE 2 CHARACTERISTIC SELECT 2-125-78
114 35 ZONE TYPE 3 ALARM EVENT CODE 7 _
115 36 ZONE TYPE 3 CHARACTERISTIC SELECT 5-1245-5678
116 36 ZONE TYPE 4 ALARM EVENT CODE 5 _
117 36 ZONE TYPE 4 CHARACTERISTIC SELECT 45-125-5678
118 36 ZONE TYPE 5 ALARM EVENT CODE 5 _
119 36 ZONE TYPE 5 CHARACTERISTIC SELECT 457-125-5678
120 36 ZONE TYPE 6 ALARM EVENT CODE 4 _
121 36 ZONE TYPE 6 CHARACTERISTIC SELECT 0-1245-5678
122 36 ZONE TYPE 7 ALARM EVENT CODE 0 _
123 36 ZONE TYPE 7 CHARACTERISTIC SELECT 2-0-78
124 36 ZONE TYPE 8 ALARM EVENT CODE 1 _
125 36 ZONE TYPE 8 CHARACTERISTIC SELECT 1-13-378
126 36 ZONE TYPE 9 ALARM EVENT CODE 7 _

GE NX-1308E - Caddx 8 Zone LED Keypad Specifications

Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP
auxiliary power with NX-320E power supply	12 VDC Regulated 2 AMPS
LED keypad current draw	130 mA max.
LED keypad zones normal w/o sounder	55 mA
NX-148E LCD keypad current draw	110 mA max.
NX-148E LCD keypad w/o sounder	75 mA

Operating Environment

operating temperature	32 to 120 degrees F

Loop Specifications

standard loop resistance	300 Ohms Maximum
2-wire smokes resistance	30 Ohms Maximum
loop response	Selectable 50mS or 500mS

Weight and Dimensions

LED keypad width	6.4"
LED keypad height	4.0"
LED keypad depth	1.1"
NX-148E LCD keypad width	6.4"
NX-148E LCD keypad height	5.3"
NX-148E LCD keypad depth	1.0"
metal enclosure width	11.25"
metal enclosure height	11.25"
metal enclosure depth	3.50"
shipping weight	9 lbs.
