NX-8 Control
51
127 36 ZONE TYPE 9 CHARACTERISTIC SELECT 6-1245-5678
128 36 ZONE TYPE 10 ALARM EVENT CODE 2 _
129 37 ZONE TYPE 10 CHARACTERISTIC SELECT 24-5-78
130 37 ZONE TYPE 11 ALARM EVENT CODE 3 _
131 37 ZONE TYPE 11 CHARACTERISTIC SELECT 3-0-0
132 37 ZONE TYPE 12 ALARM EVENT CODE 5 _
133 37 ZONE TYPE 12 CHARACTERISTIC SELECT 457-125-45678
134 37 ZONE TYPE 13 ALARM EVENT CODE 4 _
135 37 ZONE TYPE 13 CHARACTERISTIC SELECT 0-12458-5678
136 37 ZONE TYPE 14 ALARM EVENT CODE 7 _
137 37 ZONE TYPE 14 CHARACTERISTIC SELECT 5-12456-5678
138 37 ZONE TYPE 15 ALARM EVENT CODE 5 _
139 37 ZONE TYPE 15 CHARACTERISTIC SELECT 457-1256-5678
140 37 ZONE TYPE 16 ALARM EVENT CODE 4 _
141 37 ZONE TYPE 16 CHARACTERISTIC SELECT 0-12456-5678
142 38 ZONE TYPE 17 ALARM EVENT CODE 7 _
143 38 ZONE TYPE 17 CHARACTERISTIC SELECT 5-1245-25678
144 38 ZONE TYPE 18 ALARM EVENT CODE 5 _
145 38 ZONE TYPE 18 CHARACTERISTIC SELECT 457-125-25678
146 38 ZONE TYPE 19 ALARM EVENT CODE 4 _
147 38 ZONE TYPE 19 CHARACTERISTIC SELECT 0-1245-25678
148 38 ZONE TYPE 20 ALARM EVENT CODE 7 _
149 38 ZONE TYPE 20 CHARACTERISTIC SELECT 6-1245-25678
ZONE WORKSHEET
1 13 25 37
2 14 26 38
3 15 27 39
4 16 28 40
5 17 29 41
6 18 30 42
7 19 31 43
8 20 32 44
9 21 33 45
10 22 34 46
11 23 35 47
12 24 36 48

GE NX-1308E - Caddx 8 Zone LED Keypad Specifications

Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP
auxiliary power with NX-320E power supply	12 VDC Regulated 2 AMPS
LED keypad current draw	130 mA max.
LED keypad zones normal w/o sounder	55 mA
NX-148E LCD keypad current draw	110 mA max.
NX-148E LCD keypad w/o sounder	75 mA

Operating Environment

operating temperature	32 to 120 degrees F

Loop Specifications

standard loop resistance	300 Ohms Maximum
2-wire smokes resistance	30 Ohms Maximum
loop response	Selectable 50mS or 500mS

Weight and Dimensions

LED keypad width	6.4"
LED keypad height	4.0"
LED keypad depth	1.1"
NX-148E LCD keypad width	6.4"
NX-148E LCD keypad height	5.3"
NX-148E LCD keypad depth	1.0"
metal enclosure width	11.25"
metal enclosure height	11.25"
metal enclosure depth	3.50"
shipping weight	9 lbs.
