GE HEALTHCARE OPTIMA XR200AMX/XR220AMX
D
IRECTION 5336112-1EN, REVISION 3PRE-INSTALLATION MANUAL
Page 20 Section 1.4 Delivery requirements
Section 1.4 Delivery requirements
1.4.1 Product dimensions and weights
Components not listed are of negligible size and weight.
Product or
component
Length Width Height Weight Ref.
Optima XR200amx /
Optima XR220amx
119.3 cm (47 in) 55.2 cm (21.7 in)
194.0 cm (76.4 in)
standard column
or
178.8 cm (70.4 in)
short column
404 kg (891 lb) Figure 1-2
FlashPad
TM
detector
(Optima XR220amx
or Optima
XR200amx with
digital upgrade)
58 cm (22.8 in) 45.2 cm (17.8 in) 2.7 cm (1.1 in) 4.5 kg (10 lb) Figure 1-3
DAP (Optima
XR220amx or
Optima XR200amx
with digital upgrade)
146 mm (5.75 in) 198 mm (7.8 in) 45 mm (1.8 in) 0.5 kg (1.1 lb) Figure 1-4
Barcode Reader
(option, for Optima
XR220amx or
Optima XR200amx
with digital upgrade)
42 mm (1.66 in) 19 mm (0.75 in) 125 mm (4.9 in) 85 g (3 oz) Figure 1-5
