P
44x/EN PL/Hb6
Programmable Logic
(PL) 6
-14 MiCOM 40 Agile
P442, P444
Ordinal English Text Description Source
295 V>1 Start Overvoltage function 1
st
stage start for any phase
PSl (OUT)
Overvoltage
296 V>2 Start Overvoltage function 2
nd
stage start for any phase
PSl (OUT)
Overvoltage
297 V>1 Trip Overvoltage 1
st
stage 3-phase trip
PSl (OUT)
Overvoltage
298 V>2 Trip Overvoltage 2
nd
stage 3-phase 2 trip
PSl (OUT)
Overvoltage
299 I2> Start
Negative Sequence Current Detection – Start function
(the associated time-delay picks up)
Directional or not - with DT curves
Negative-sequence polarization
PSL (OUT)
Neg Seq.
O/C
300 I2> Trip
Negative Sequence Current Trip – 3P trip command
issued when the associated time-delay has elapsed
PSL (OUT)
Neg Seq.
O/C
301 I> Start Any A Any overcurrent start for phase A
PSL (OUT)
Phase Overc.
302 I> Start Any B Any overcurrent start for phase B
PSL (OUT)
Phase Overc.
303 I> Start Any C Any overcurrent start for phase C
PSL (OUT)
Phase Overc.
304 I>1 Start
Overcurrent stage 1 start
Directional or not - with DT or IDMT curves
Directional managed by Delta Algorithms
VTS Block time-delay facility
PSL (OUT)
Phase Overc.
305 I>2 Start
Overcurrent stage 2 start
Directional or not - with DT or IDMT curves
Directional managed by Delta Algorithms
VTS Block time-delay facility
PSL (OUT)
Phase Overc.
306 I>3 Start
Overcurrent stage 3 start
Non-directional with DT curves
Use without time-delay for SOTF
PSL (OUT)
Phase Overc.
307 I>4 Start
Overcurrent stage 4 start
Non-directional with DT curves
Use without time-delay for SOTF
PSL (OUT)
Phase Overc.
308 I>1 Trip
Overcurrent stage 1 trip (3P issued when the associated
time-delay has elapsed).
Set to 0: Reset I>1 Trip command
PSL (OUT)
Phase Overc.
309 I>2 Trip
Overcurrent stage 2 trip (3P issued when the associated
time-delay has elapsed).
Set to 0: Reset I>2 Trip command
PSL (OUT)
Phase Overc.
310 I>3 Trip
Overcurrent stage 3 trip (3P issued when the associated
time-delay has elapsed).
Set to 0: Reset I>3 Trip command
PSL (OUT)
Phase Overc.
311 I>4 Trip
Overcurrent stage 4 trip (3P issued when the associated
time-delay has elapsed).
Set to 0: Reset I>4 Trip command
PSL (OUT)
Phase Overc.
312 SOTF Enable
Switch On To Fault enabled: Indicates the SOTF logic is
enabled in the relay
Set to 1 = [SOTF not disabled (Setting 'Distance
schemes /
TOR-SOTF Mode')]
AND [ { All poles dead AND (SOTF time-delay
elapsed
(110 s/default)) }
OR Input Man Close]
OR (CB control & Close in progress)]
Reset = 500 ms time-delay elapsed after Any
pole Dead
OR Reset of one condition requested for SOTF
enable
PSL (OUT)
SOTF
