P44x/EN PL/Hb
MiCOM 40 Agile P442, P444
(PL) 6-
Ordinal English Text Description Source
313 TOR Enable
Trip On Reclose enable: indicates the TOR logic is
activated in the relay
Set to 1= 500 ms pulse initiated by:
'I A/R Reclaim' (internal) OR 'A/R reclaim' (External
Input)
OR Any pole open for more than 200 ms
Reset 500 ms after Any pole dead stops
PSL (OUT)
TOR
314 TOC Start A
Trip on Close start on phase A: indicates a trip order on
phase A has been issued by the SOTF level detectors
(Pickup time-delay = 20 ms)
PSL (OUT)
SOTF
315 TOC Start B
Trip on Close start on phase B: indicates a trip order on
phase B has been issued by the SOTF level detectors
(Pickup time-delay = 20ms)
PSL (OUT)
SOTF
316 TOC Start C
Trip on Close start on phase C: indicates a trip order on
phase C has been issued by the SOTF level detectors
(
Pickup time-delay = 20 ms)
PSL (OUT)
SOTF
317 Any start Any protection start logic with any phase
Default PSL: LED 4, Relay 06
(Fault record trigger in default PSL with 20 ms Dwell
Timer)
PSL (OUT)
All protection
318 1ph Fault Single phase fault
PSL (OUT)
Distance
319 2ph Fault Two phase fault
PSL (OUT)
Distance
320 3ph Fault Three phase fault
PSL (OUT)
Distance
321 Any Trip Single or three pole trip or external protection trip
Default PSL: Relay 07
PSL (OUT)
All protection
322 Any Int. Trip A
Any internal protection A phase trip
Default PSL: LED 1, Relay 02
PSL (OUT)
All protection
323 Any Int. Trip B
Any internal protection B phase trip
Default PSL: LED 2, Relay 03
PSL (OUT)
All protection
324 Any Int. Trip C
Any internal protection C phase trip
Default PSL: LED 3, Relay 04
PSL (OUT)
All protection
325 Any Trip A Any trip A (internal or external protection)
PSL (OUT)
All protection
326 Any Trip B Any trip B (internal or external protection)
PSL (OUT)
All protection
327 Any Trip C Any trip C (internal or external protection)
PSL (OUT)
All protection
328 1P Trip Single pole trip (internal or external)
PSL (OUT)
All protection
329 3P Trip Three pole trip (internal or external)
PSL (OUT)
All protection
330 Brk.Conduct.Trip Broken conductor trip
PSL (OUT)
Broken Cond.
331 Loss. Load Trip
Loss of load trip (in application without communication
scheme and a 3P Trip logic)
PSL (OUT)
Loss of load
332 SOTF/TOR Trip
Switch on to fault trip or trip on reclose: indicates that a
3-pole trip order has been issued by the TOR or SOTF
logic
PSL (OUT)
SOTF
333 tBF1 Trip
Circuit Breaker failure on any trip, delayed by "CB Fail 1
Timer" (setting in "CB Fail" logic)
PSL (OUT)
Breaker
failure
334 tBF2 Trip
Circuit Breaker failure on any trip, delayed by "CB Fail 2
Timer" (setting in "CB Fail" logic)
PSL (OUT)
Breaker
failure
335 Control Trip Control trip command from user (by internal CB control)
PSL (OUT)
CB control
